Lindemann Audio Limetree Network II Player

Lindemann Audio Limetree Network II Player

The Limetree Network by Lindemann Audio was a network player designed to playback music from streaming services or local storage media in studio master quality. The new Network II represents a total revision of the original, with changes made to the features, ease of use and ultimately the sound produced.

What Lindemann say

The Limetree NETWORK is a high-grade network player which can playback music from streaming services and local storage media in studio master quality. It is connected to the network with a LAN cable or via WLAN. It offers an additional USB port for docking hard disk drives or USB storage media. Besides an analogue line-level output, the network player also features a high-quality headphone output.

New Features

D/A converter and analogue output stage (new development):

• Converter module ES9038 Sabre DAC. Ultra high resolution, integrated DPLL and SRC for jitter elimination. Briefly, one of the best D/A converter chips on the market.
• MEMS femto-clock < 500 fs clock jitter. Extremely stable clock with ultra-low phase noise for best sound results.
• High-quality analogue level control. Thus extremely low noise level. HF intermodulation of the converter module is attenuated together with the volume. Full resolution even at low levels.
• Excellent sounding headphone amplifier with high output current. Ultra-low distortions, high damping factor, drives headphones from 16 to 300 ohms.
• IR remote control for volume, mute and track selection.
• CD player operation – with external CD-ROM drive.

Integrated preamp with extended functions:

• Separate volume control for headphone and line output. Perfect for simultaneous operation with headphones and loudspeakers. Each output will remember its last volume setting.
• Balance control with a +/- 6 dB setting range (in 1 dB steps).
• Headphone volume with ideal gain range: 0 dB / + 12 dB. Useful e.g. with low-sensitivity magnetos.

Additional app settings:

• 7 different oversampling filters selectable.
• Balance +/- 6 dB
• Headphone output low/high
• LED brightness low/high

Features

	The LINDEMANN streaming platform offers a studio master grade reproduction. Either through a LAN connection or wireless via WLAN. Due to WPS, integrating the device into your existing system is just a breeze. Moreover, the ARM core high-performance processor and the web update feature make the platform absolutely future-proof.
	Technically speaking, the Limetree NETWORK is way ahead: all digital signals can be converted into DSD 256, a data format which is highly esteemed by audiophiles worldwide. This radical new approach also lets "normal" recordings in CD quality shine with an exceptionally good sound.
	The Limetree NETWORK is equipped with a high-quality headphone amplifier, but may also be connected directly to an amplifier or active loudspeakers via the line output on the rear side.
	A special highlight is our multi-room function which allows to run several streamers in different rooms separately or coupled. These are conveniently controlled via the LINDEMANN app.
	The LINDEMANN app is available for Android and iOS, both for smartphones and tablets. The album-oriented programming convinces by fluent browsing and an easy, intuitive operation. Our definitive highlight.
	Via USB the Limetree NETWORK supports the connection of external CD drives and thus turns easily into a top-class CD player at little cost! And this, of course, plug-and-play; the drive is automatically recognized and integrated via the LINDEMANN app. Including control and CD text support.
	The Limetree NETWORK offers a Bluetooth function which enables a wireless music playback e.g. from smartphones or tablets. At the same time the A2DP Bluetooth audio transmission protocol ensures the very best sound quality.

The Lindemann app

The Limetree NETWORK is controlled almost exclusively via the newly designed Lindemann app which is available both for Android and iOS. Apart from the smartphone version, there is also a proprietary tablet version in the landscape mode. The app allows a fluent, intuitive browsing and searching. A new feature is the simultaneous display of browse view and play view. In addition you can also call up your current play queue. The album-oriented programming allows the playback of a complete album with just one push of a button!

In addition, the specially integrated multi-room function also allows to run several streamers in different rooms separately or coupled. The range of streaming services is diversified, with a clear focus on studio master quality and hi-fi subscriptions. Customers may choose between TIDAL, Qobuz, Deezer, HighResAudio and Spotify. Through Lindemann's partner airable you will also get access to thousands of podcasts and radio stations worldwide.

Specification

• Resolution: 384 kHz/32 bit and DSD 256
• Dynamic range: > 120 dB
• THD & Noise: < 0.001 % (@ 0 dB FS)
• Clock: ultra low jitter MEMS FemtoClock
• Re-sampling: bit-perfect or DSD
• Converter architecture: two AK4452 DACs in dual differential mono mode, AK4137 re-sampler
• Output voltage: 2.0 V @ 0 dB FS
• Output impedance line output: 100 ohms
• Headphone connector: 3.5 mm mini jack socket
• Recommended headphone impedance: 32 -200 ohms
• Ethernet: 100 Mbit/s
• WLAN: dual-band 802.11a/b/g/n/ac
• Bluetooth 4.2, A2DP
• USB 2.0 high-speed host interface, max. output current 1.5 A
• Supported codecs: WAV, FLAC, AIFF, ALAC, MP3, AAC, Ogg Vorbis, WMA, DSD
• UPnP und DLNA support
• PCM resolution: 44.1 kHz up to 384 kHz, 24 bit.
• DSD resolution: DSD 64 up to DSD 256.
• Gapless playback
• Streaming services: TIDAL, Qobuz, Deezer, HighResAudio, Spotify, Internet radio and Podcast
• Roon Ready
• Power consumption: 0.1 W standby, 3.5 W operation, 11 W max.
• Dimensions (W x H x D): 107 x 40 x 107 mm (4.2 x 1.6 x 4.2 in)
• Weight: 300 g (0.66 lbs)
• Power supply: 5V DC
