Atlas Ascent Ultra 75 Ohm SP-DIF Digital Audio Cable

As low as £205.50 £171.25
SKU
Atlas Ascent SP-DIF
5 Years
New
24 hours
what's this?

We can burn-in your cable for up to 96 hours FREE of charge using our Nordost VIDAR cable burner. This is a £3000 machine that will optimise the performance of your cables from day one. This means the cables will be in optimum performance mode when you receive them, so you'll be able to make a performance assessment quickly rather than waiting 70 hours+ of usage. The result of conditioning cables with the Nordost VIDAR is, improved sound staging, increased detail, and an overall more musical presentation. Please Note: we are unable to burn-in cables with stripped bare ends or BFA-only plugs. (This does not apply to BFA/Banana plugs). Cables are burnt-in for the selected period AFTER your order has been processed. This service is offered at Future Shop's discretion and we cannot guarantee all burn-in requests are fully completed during busy periods.

what's this?

Select the desired length for your cable from the drop-down menu.

what's this?
SPEAKER CABLES:

A quantity of 2 means you will receive a pair of speaker cables e.g. for your front left and front right speakers. By entering a quantity of 1, you will get a cable for a single speaker e.g. centre speaker and this option also enables you to vary the length (and termination) of your cable for each speaker.

OTHER CABLES:

A quantity of 1 means you will receive a single cable in the case of aerial, satellite, subwoofer, digital coaxial & optical cables and a pair of cables in the case of 2 rca to 2 rca analogue audio cables.

NON-CABLE PRODUCTS:

A quantity of 1 means you will receive 1 of the specified products.

Available

Need help? Call us on 0800 772 3688 or 0208 905 1555

Prefer email? Contact us via sales@futureshop.co.uk

The Atlas Ascent Ultra 75 Ohm SP-DIF digital cable is a superb cable which gives a considerable insight into the state-of-the-art performance of Atlas' ‘high-end’ Mavros interconnect at a very reasonable price. Ascent was designed to be technically and sonically superior to competing digital cables currently available at similar prices.

Atlas Ascent Ultra 75 Ohm SP-DIF Digital Audio Cable



The Atlas Ascent Ultra 75 Ohm SP-DIF digital cable is a superb cable which gives a considerable insight into the state-of-the-art performance of Atlas' ‘high-end’ Mavros interconnect at a very reasonable price. Ascent was designed to be technically and sonically superior to competing digital cables currently available at similar prices.

The central conductor is made from OCC copper which is insulated by an extremely low-loss PEF (Foamed Polyethylene) dielectric. The tightly woven wire mesh together with an aluminium outer foil provides 100% rejection of RFI (Radio Frequency Interference) ensuring the music signal is free from any external noise. The cable is covered by a soft PVC sleeve and finished in a grey woven fabric.

The Ascent digital cable is terminated with Atlas' cold-weld connected wideband Ultra RCA plugs. The result is a smooth, uninterrupted signal path which behaves as one continuous entity, with minimal degradation of the signal compared to soldered connections. This is particularly important in a digital cable, connectors which compress the cable can actually alter the cable’s impedance, which drops below the 75 Ohm specification, typically by up to 50%, reducing accuracy of the signal transfer.



Features :

  • Ultra RCA Plugs
  • OCC Copper Conductors
  • PEF Dielectric
  • Co-ax Construction


Ultra RCA Plug

The Ultra is a wide-band, OCC copper, constant impedance, self-cleaning, solder-free construction RCA plug.
In Atlas' cables, the conductor to plug interfaces are solder free, and the gold-plated conjugate brackets act as the return signal path, helping to reject RFI. Both conjugate brackets (these grip the cable without the adverse effects of compressing it, which can alter impedance) have two asymmetrical leaves which spring open on insertion and wipe clean the signal path. To maintain a clean signal path, simply remove and re-insert them periodically.

The Ultra RCA connectors utilise low-mass non-magnetic connectors to minimise the negative effect of excessive metal in the plug itself.

Atlas Ultra RCA Plug Technical Diagram

Ohno Continuous Casting Copper (OCC Copper)

The Ohno continuous casting method re-heats the extrusion as the molten copper is forced out of the mould and very slowly and gradually draws the grain or crystal down the conductor''s length, creating a ‘single crystal structure.’ Actually, because no copper is 100% pure, there will always be a few boundaries produced by impurities. The frequency of boundaries created are quite insignificant. A typical crystal in a copper conductor drawn to 0.3 mm diam. using the OCC process is 125.00 metres long!

The benefits are obvious, with almost no crystal boundaries, the audio signal is no longer impeded down the copper wire and more information and detail is delivered faithfully to the receiving equipment.

Atlas OCC Copper Design Process

Copper Purity Comparison (0.3mm Diameter)
  TPC OFC OCC
Purity >99.9% >99.99% >99.999%
Specific Gravity 8.75 8.926 8.938
Gas Impurities (ppm)
O2 200~500 <10 <5
H2 <0.5 <0.5 <0.3
Average Crystal Size (Metre) 0.007 0.02 125.00
Crystals Per Metre 150 50 0.008


PEF Dielectric


PVC (Poly Vinyl Chloride) is cheap to produce and, as such, is the most commonly used insulation in AV cables. However, PVC is the worst quality insulation a Hi-Fi or AV signal can encounter as its high loss causes a significant reduction in signal velocity. PVC is better suited to power cables and should be avoided in Hi-Fi and AV signal cables.

Other dielectrics in common use are Polyethylene, Polypropylene and Polytetrafluoride Epoxy (better known as PTFE (Teflon™) or Teflon,) and the new and unique Atlas (PTFE).

PEF (Foamed Polyethylene). The foaming process uses a blowing agent, of which there are two types. Atlas use the gas-foamed method which creates a more inert, consistent and higher quality product.

The table below shows the properties of a selection of dielectrics. Though not used as a dielectric in Atlas' cables, PVC is included for comparison purposes.

Dielectric Material Comparison (0.3mm Diameter)
Property Polyvinyl Chloride
(PVC)
Foamed Polyethylene
(PEF)
Polypropylene
(P.P)
Teflon
(FEP or PTFE)
PTFE
Dielectric Constant
(@ 50 -106Hz)
4-8 2.3 2.25 2.1 1.3
Dielectric Strength
(kV mm-1)
23-30 30-50 30-50 20-25 N/A
Loss Tangent
(% @ 50 - 106Hz)
8-15 0.02-0.05 0.02-0.06
(@ 106Hz)
0.02-0.07 N/A
Volume Resistivity
(Ohms.cm @ 20°C)
1012-15 >1017 6.5x1014 >1016 N/A
Tensile Strength
(Kg mm-2)
1.0-2.5 1.0-2.0 3.0-4.0 1.9-2.2 1.0
Melting Point
(°C)
-130 112-120 155-160 275 275
Max. Continuous Operating Temp.
(°C)
60 75 90 200 260
Min. Operating Temp.
(°C)
-15 to -40 <-60 -5 to -45 <-60 -250


Co-ax Construction

Central conductor (signal path) surrounded by dielectric material encased within a circular conducting screen which acts as the signal return path.




Specification :

  • Construction : Co-ax
  • Material : OCC
  • Dielectric : PEF (Foamed Polyethylene)
  • Screen : Braid + Al Mylar™
  • Capacitance : 59.37 pF/m
  • Inductance : 0.473 µH/m
  • Resistance : 0.7311 Ohms/m
  • Impedance : 73.11 Ohms at (1MHz)
  • VOP : 0.81
  • Outside Diameter : 8.5mm



About Atlas Cables Made in United Kingdom

Atlas Cables are a major producer of interconnects and cables in the United Kingdom of Great Britain. All products are researched, developed and most are assembled in the Atlas purpose built factory in Scotland.

Many of these products are unique and use advanced techniques of production or manufacture in order to bring to the user the very finest quality products. With each new model we continue to push the boundaries of reliability and performance. It's little wonder then, that Atlas Cables have had so many mile-stone advances in the past and that Atlas Cables have secured so many awards in comparative tests against other products.

Specification :

  • Construction : Co-ax
  • Material : OCC
  • Dielectric : PEF (Foamed Polyethylene)
  • Screen : Braid + Al Mylar™
  • Capacitance : 59.37 pF/m
  • Inductance : 0.473 µH/m
  • Resistance : 0.7311 Ohms/m
  • Impedance : 73.11 Ohms at (1MHz)
  • VOP : 0.81
  • Outside Diameter : 8.5mm
