Atlas Asimi Transpose Speaker Jumper Links - Pack of 4

Item code: Atlas Asimi Jumper Links

Atlas' ‘ultimate’ speaker cable. Performance without compromise. A reference class pure silver speaker cable engineered for the world’s finest audio systems.
£2,362.50
£1,968.75
✓ Save %

Lowest price in the last 30 days:

New 5 Years warranty 60-day returns
Outside the UK? VAT removed automatically at checkout. Pre-paid duties available for selected destinations.
Please choose:

Termination

*

Please select from the available options for plug terminations.

Configured total
£1,968.75 Ex. VAT
Qty:

SPEAKER CABLES:

A quantity of 2 means you will receive a pair of speaker cables e.g. for your front left and front right speakers. By entering a quantity of 1, you will get a cable for a single speaker e.g. centre speaker and this option also enables you to vary the length (and termination) of your cable for each speaker.

OTHER CABLES:

A quantity of 1 means you will receive a single cable in the case of aerial, satellite, subwoofer, digital coaxial & optical cables and a pair of cables in the case of 2 rca to 2 rca analogue audio cables.

NON-CABLE PRODUCTS:

A quantity of 1 means you will receive 1 of the specified products.

£1,968.75 ex. VAT
Available — built to order, dispatches in 3 - 5 Days
Delivery: Royal Mail Tracked 24 FREE  ·  DPD Next Day from £8.95  ·  DPD Saturday from £12.95
Order before 4pm (Mon–Fri) for same-day dispatch
Our promise: 60-day returns · Free burn-in · Built in our UK workshop · 5 Years warranty · Expert support on every order
promotional_banner_4

Atlas Asimi Transpose Speaker Jumper Links - Pack of 4



Atlas' ‘ultimate’ speaker cable. Performance without compromise. A reference class pure silver speaker cable engineered for the world’s finest audio systems. Asimi uses very high purity OCC (Ohno Continuous Casting) silver conductors.

The OCC process is named after professor Atsumi Ohno, who in the late 1970s, discovered that by heating the drawing mould to a higher temperature than the molten copper you intend to cast, then cooling it soon after, the result is one long, high purity (99.99997%) metal crystal. Criticism of silver cables as generally ‘bright’ are in fact the result of impurities and grain in the inferior conductors used.

The Asimi’s high-purity monocrystal conductors are arranged in a complex multi-stranded layout, with each cable leg composed of 3 pairs of solid conductors each of different diameter, totalling 3.5mm² – an unusually high figure, given the cost of this purity of silver. In most silver cables, the conductor size is compromised to reduce cost –but which explains why some critics suggest silver cables offer the listener very sweet highs but no weight or authority at low frequencies. That’s certainly not true of the Asimi, with several reviewers commenting on the sense of physical presence conveyed.

Atlas' focus was also on the coating that insulates and protects the silver. The Asimi has these conductors enveloped in our microporous Teflon dielectric. This new air-spaced material improves on the performance of the best solid Teflon or PTFE (Teflon™) insulators, by providing a 30% greater signal velocity and superior integrity, particularly in high frequency delivery. This is achieved because the new material has a dielectric constant of around 1.5 (the lower the number the better), significantly better than the 2.1 typically achieved by the PTFE (Teflon™) insulators which were previously the best available in these applications.

This obsessive attention to detail – and the combination of materials & assembly methods which was only finalised after exhaustive testing – produces a cable which HiFi World’s reviewer described as‘ the best he’d ever heard’ and HiFi Plus summarised as ‘one of the very, very best.’

Atlas' goal to make cables which have no discernable character or sound of their own, which would in itself be a form of distortion – Asimi is engineered to ‘disappear’ in your system, conveying the performance of your equipment with total transparency.

It should be noted though that Asimi requires a ‘burn-in’ period during which the sound will continue to improve.



Features :

  • Transpose Modular Speaker Connectors
  • OCC Silver Conductors
  • PTFE Dielectric
  • Solid Multi-Core Construction


Transpose Modular Speaker Connector

The Transpose is a modular, cold-weld, air-tight, solder-free speaker plug. Interchangeable connector options are spade, Z-plug and expanding plug, available in gold or silver.

In a cold-weld connection, the metal of the connector plug and the wire are squeezed together under a calibrated pressure to form a robust, consistent, air-tight metal to metal contact with no damage to the cable dielectric. The result is a smooth, uninterrupted signal path which behaves as one continuous entity, with minimal degradation of the signal compared to soldered connections.

Atlas Transpose Plugs Technical Diagram

Ohno Continuous Casting Silver (OCC Silver)

The Ohno continuous casting method re-heats the extrusion as the molten copper is forced out of the mould and very slowly and gradually draws the grain or crystal down the conductor''s length, creating a ‘single crystal structure.’ The benefits are obvious, with almost no crystal boundaries, the audio signal is no longer impeded down the copper wire and more information and detail is delivered faithfully to the receiving equipment.

Silver, with its lower resistivity, is a better conductor than copper, but any conductor, whether silver or copper, must have a reasonable cross-sectional area when used for audio applications. Silver is much more expensive than copper and, in order to keep costs within reason, the cross sectional area of silver audio cables are often compromised and the resulting sound is ‘bass light.’ Good silver cables are, however, fast, dynamic and seamless through the audio spectrum and provide exceptional detail and instrument resolution. The Atlas Asimi cables employ OCC silver conductors and in the case of the Asimi speaker cable, these are a substantial 3.5 sq mm in overall size in order to provide wide bandwidth and superior definition.

Atlas OCC Silver Design Process



PTFE Dielectric

PVC (Poly Vinyl Chloride) is cheap to produce and, as such, is the most commonly used insulation in AV cables. However, PVC is the worst quality insulation a Hi-Fi or AV signal can encounter as its high loss causes a significant reduction in signal velocity. PVC is better suited to power cables and should be avoided in Hi-Fi and AV signal cables.

Other dielectrics in common use are Polyethylene, Polypropylene and Polytetrafluoride Epoxy (better known as PTFE (Teflon™) or Teflon,) and the new and unique Atlas (PTFE).

Microporous PTFE (Teflon™) is a unique, low density dielectric material, phase stable at room temperature, which offers significant performance improvements over solid PTFE (Teflon™) dielectric designs.

The table below shows the properties of a selection of dielectrics. Though not used as a dielectric in Atlas' cables, PVC is included for comparison purposes.

Dielectric Material Comparison (0.3mm Diameter)
Property Polyvinyl Chloride
(PVC)
Foamed Polyethylene
(PEF)
Polypropylene
(P.P)
Teflon
(FEP or PTFE)
PTFE
Dielectric Constant
(@ 50 -106Hz)
4-8 2.3 2.25 2.1 1.3
Dielectric Strength
(kV mm-1)
23-30 30-50 30-50 20-25 N/A
Loss Tangent
(% @ 50 - 106Hz)
8-15 0.02-0.05 0.02-0.06
(@ 106Hz)
0.02-0.07 N/A
Volume Resistivity
(Ohms.cm @ 20°C)
1012-15 >1017 6.5x1014 >1016 N/A
Tensile Strength
(Kg mm-2)
1.0-2.5 1.0-2.0 3.0-4.0 1.9-2.2 1.0
Melting Point
(°C)
-130 112-120 155-160 275 275
Max. Continuous Operating Temp.
(°C)
60 75 90 200 260
Min. Operating Temp.
(°C)
-15 to -40 <-60 -5 to -45 <-60 -250


Solid Multi-Core Construction

Monocrystal conductors arranged as 3 pairs of solid conductors each of different diameter.


Specification :

  • Construction : Solid multicore
  • Material : OCC pure silver
  • Dielectric : Microporous PTFE (Teflon™)
  • Capacitance : 34.06 pF/m
  • Inductance : 0.529 µH/m
  • Resistance : 0.0046 Ohms/m
  • VOP : 0.79
  • Outside Diameter : 16.3mm



About Atlas Cables Made in United Kingdom

Atlas Cables are a major producer of interconnects and cables in the United Kingdom of Great Britain. All products are researched, developed and most are assembled in the Atlas purpose built factory in Scotland.

Many of these products are unique and use advanced techniques of production or manufacture in order to bring to the user the very finest quality products. With each new model we continue to push the boundaries of reliability and performance. It's little wonder then, that Atlas Cables have had so many mile-stone advances in the past and that Atlas Cables have secured so many awards in comparative tests against other products.

About Atlas Cables

Scottish cable maker that designs and builds its own conductors, connectors and cables rather than assembling bought-in parts.

Atlas researches, designs and produces its cables in Scotland, with a handful of exceptions. Many cable brands assemble off-the-shelf components, but Atlas specifies the conductors, insulation and terminations itself and tests the result in its own listening room. It offers a five-year guarantee on its cables.

Read more about Atlas Show less

The plugs are Atlas designs too

Atlas designs its own RCA plugs. The Achromatic and Ultra RCAs are built for low mass and high bandwidth, and the newer Metik connectors were developed for personal audio. Designing the connectors in house means Atlas is not limited to what an outside supplier already sells.

Three performance levels, with named ranges in each

The catalogue is arranged in three performance levels. Upgrade covers Element and Equator, Aspire covers Hyper and Ailsa, and High End covers Mavros, Arran, Eos and Zeno. You can choose the level that suits the rest of your system, then move up later without changing brand.

Custom options and a repair service

Atlas lists luxe and speaker termination options, so you can specify a cable to suit the equipment at each end. It also repairs, customises and upgrades its cables through a dedicated service, which means you can bring an older cable up to date instead of replacing it.

Why we stock Atlas

Atlas run pure copper conductors through most of the range rather than silver or silver plating. That gives a warmer, more forgiving balance than the silver-plated cables we sell. If your system is already leaning bright, Atlas is usually where we point you first. Hand-built in Scotland, and we have sold them since 2008.

Shop all Atlas Cables →

Specification :

  • Construction : Solid multicore
  • Material : OCC pure silver
  • Dielectric : Microporous PTFE (Teflon™)
  • Capacitance : 34.06 pF/m
  • Inductance : 0.529 µH/m
  • Resistance : 0.0046 Ohms/m
  • VOP : 0.79
  • Outside Diameter : 16.3mm
