Blustream HEX70ARC-KIT HDBaseT™ ARC Extender Set - 70m (4K up to 40m)
£412.00 £343.33
SKU
HEX70ARC-KIT
Free UK Delivery
5 Years
New
24 hours
The HEX70ARC-KIT 4K HDBaseT™ ARC extender set offers market leading features for the custom installation industry. The product delivers HDMI, ARC, Optical Audio Return, Bi-directional IR and Bi-directional PoC (Power over Cable) up to lengths of 70m (40m at 4K 60Hz 4:2:0).
Blustream HEX70ARC-KIT HDBaseT™ ARC Extender Set - 70m (4K up to 40m)
The Blustream HEX70ARC-KIT HDBaseT™ ARC Extender Set is a cutting-edge solution designed specifically for the custom installation industry. Packed with market-leading features, this extender set delivers unparalleled performance and versatility, revolutionizing your audiovisual experience.
With advanced HDBaseT™ technology, the HEX70ARC-KIT provides uncompressed video and audio transmission with zero latency. It extends HDMI 1080p signals up to an impressive 70m over a single CAT cable, ensuring reliable and consistent performance even over long distances.
Experience the brilliance of 4K UHD video with support for resolutions up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0). Enjoy stunning visuals and immersive content, bringing your movies, games, and presentations to life with exceptional clarity.
The HEX70ARC-KIT is designed to accommodate various video resolutions, including VGA-WUXGA and 480i-4K, ensuring compatibility with a wide range of display devices and sources.
One of the standout features of this extender set is its support for ARC (Audio Return Channel). With ARC, you can seamlessly transfer audio from the connected display back to the audio system using either the HDMI ARC or optical digital input. This simplifies your audio setup and eliminates the need for additional audio cables.
The HEX70ARC-KIT offers additional flexibility with its HDMI loop-out on the HEX70ARC-TX unit. This allows you to integrate local displays or cascade the signal to multiple devices, expanding your connectivity options and enhancing your viewing experience.
Enjoy an immersive audio experience with support for all known HDMI audio formats, including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus, and DTS-HD Master Audio transmission from the transmitter (TX) to the receiver (RX). Immerse yourself in rich, high-fidelity sound that complements the stunning visuals.
Control your setup effortlessly with the bi-directional IR pass-through feature. This allows you to transmit IR signals between the transmitter and receiver units, providing convenient control over your connected devices.
The HEX70ARC-KIT comes complete with a Blustream IR receiver and emitter, ensuring seamless integration into your audiovisual system.
Powering the extender set is made simple with bi-directional PoC (Power over Cable). You can power the extenders from either the transmitter or receiver end, eliminating the need for additional power connections and simplifying installation.
Rest assured that the HEX70ARC-KIT is HDCP 2.2 compliant and features smart EDID management, ensuring optimal compatibility and smooth operation with a wide range of source devices and displays.
Unlock the true potential of your audiovisual setup with the Blustream HEX70ARC-KIT HDBaseT™ ARC Extender Set. Experience unrivalled performance, seamless connectivity, and exceptional audiovisual quality. Upgrade your installation and elevate your audiovisual experience to new heights.
Features
- Advanced HDBaseT™ technology offering uncompressed video and audio with zero latency
- Extends HDMI 1080p up to a distance of 70m over a single CAT cable
- Supports 4K UHD video up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
- Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
- Supports ARC (Audio Return Channel) from connected display via HDMI ARC or optical digital input
- Features 1 x HDMI loop-out on HEX70ARC-TX for integrating local displays or cascading to multiple devices
- Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission (TX to RX)
- Bi-directional IR pass-through
- Supplied with Blustream IR receiver and emitter
- Supports bi-directional PoC (Power over Cable) to power extenders from either transmitter or receiver end
- HDCP 2.2 compliant with smart EDID management
Advanced Audio Return Channel (ARC) Functionality
The three modes for Audio Return and CEC are controlled using the switch located on the Receiver unit. The switch positions are HDMI, PASS or OPT. See below for explanation:
HDMI - HDMI ARC in to the Receiver from the display, to Optical Out and L/R Out on the Transmitter. CEC communication over HDBaseT™ is blocked.
PASS - HDMI ARC in to the Receiver from the display to HDMI ARC, Optical Out and L/R Out on the Transmitter. CEC communication is passed through the HDBaseT™ link.
OPT - Optical audio in to the Receiver from the display, to Optical Out and L/R Out on the Transmitter. CEC communication over HDBaseT™ is blocked.
Specification
- HEX70ARC-TX
- Video Input Connectors: 1 x HDMI Type A, female
- Video Output Connectors: 1 x HDBaseT™ RJ45 connector, 1 x HDMI Type A, female
- Audio Output Ports: 1 x Optical (S/PDIF), 1 x 3.5mm L/R analogue audio
- IR Input Port: 1 x 3.5mm stereo jack
- IR Output Port: 1 x 3.5mm mono jack
- Product Upgrade: 1 x Micro-USB, female
- Casing Dimensions (W x D x H): 135 x 84 x 21mm
- HEX70ARC-RX
- Video Input Connectors: 1 x HDBaseT™ RJ45 connector
- Video Output Connectors: 1 x HDMI Type A, female
- Audio Input Port: 1 x Optical (S/PDIF)
- IR Input Port: 1 x 3.5mm stereo jack
- IR Output Port: 1 x 3.5mm mono jack
- Product Upgrade: 1 x Micro-USB, female
- Casing Dimensions (W x D x H): 135 x 84 x 21mm
- Power Supply: 1 x 24V/1.25A DC, 4-pin DIN connector
- Box Dimensions (W x D x H): 248 x 151 x 103mm
- Shipping Weight: 1kg
- Operating Temperature: 32°F to 104°F (-5°C to +55°C)
- Storage Temperature: -4°F to 140°F (-25°C to +70°C)
Contents
- 1 x HEX70ARC-TX
- 1 x HEX70ARC-RX
- 1 x 24V/1.25A DC Power Supply
- 1 x IR Emitter
- 1 x IR Receiver
- 2 x Mounting Bracket Sets
- 1 x Quick Reference Guide
 |
 |
 |
 |
 |
 |
 |
 |
About Blustream
Blustream is a leading provider of advanced HDMI distribution solutions in the audio-visual industry. With over 30 years of experience, the company's products are designed and engineered by a global team of AV specialists. Blustream's research revealed the need for an AV distribution brand that delivers industry-leading performance and reliability. To address this, the company has developed a range of HDBaseT, Video over IP, and HDMI solutions that provide seamless AV integration within any installation environment.
Blustream is an official adopter and alliance member of HDBaseT, positioning the company at the forefront of this advanced technology. Blustream's engineers have created the world's most innovative range of AV distribution products by integrating the latest pioneering chipsets. The company's dedication to quality and innovation has earned it numerous awards in the audio-visual industry, making Blustream the go-to option for advanced HDMI distribution.
Specification
- HEX70ARC-TX
- Video Input Connectors: 1 x HDMI Type A, female
- Video Output Connectors: 1 x HDBaseT™ RJ45 connector, 1 x HDMI Type A, female
- Audio Output Ports: 1 x Optical (S/PDIF), 1 x 3.5mm L/R analogue audio
- IR Input Port: 1 x 3.5mm stereo jack
- IR Output Port: 1 x 3.5mm mono jack
- Product Upgrade: 1 x Micro-USB, female
- Casing Dimensions (W x D x H): 135 x 84 x 21mm
- HEX70ARC-RX
- Video Input Connectors: 1 x HDBaseT™ RJ45 connector
- Video Output Connectors: 1 x HDMI Type A, female
- Audio Input Port: 1 x Optical (S/PDIF)
- IR Input Port: 1 x 3.5mm stereo jack
- IR Output Port: 1 x 3.5mm mono jack
- Product Upgrade: 1 x Micro-USB, female
- Casing Dimensions (W x D x H): 135 x 84 x 21mm
- Power Supply: 1 x 24V/1.25A DC, 4-pin DIN connector
- Box Dimensions (W x D x H): 248 x 151 x 103mm
- Shipping Weight: 1kg
- Operating Temperature: 32°F to 104°F (-5°C to +55°C)
- Storage Temperature: -4°F to 140°F (-25°C to +70°C)
Contents
- 1 x HEX70ARC-TX
- 1 x HEX70ARC-RX
- 1 x 24V/1.25A DC Power Supply
- 1 x IR Emitter
- 1 x IR Receiver
- 2 x Mounting Bracket Sets
- 1 x Quick Reference Guide
