EL-8400VA – 6 x 2 Presentation Seamless Matrix with USB & Audio/Mic I/O plus a built-in audio amplifier
The CYP EL-8400VA is a 6x2 seamless presentation matrix with integrated scaling, built to route and switch a mix of source formats to two displays in boardrooms, lecture theatres, classrooms and similar presentation spaces. It takes six video inputs, comprising three HDMI, one DisplayPort, one USB Type-C and one HDBaseT2 input, and routes any source to its two outputs, one HDMI and one HDBaseT2, sending the selected signal over Cat.6A cable up to 100 metres alongside bi-directional Ethernet, RS-232, USB and IR. Seamless switching means sources change instantly with no black screen or delay, and built-in scaling ensures every source is presented cleanly at the display's native resolution.
The HDMI, DisplayPort and USB-C inputs support resolutions up to 4K@60 in full 4:4:4 colour at 8-bit, while the HDBaseT output automatically down-converts 4K60 4:4:4 sources to 4K60 4:2:0 to suit the link, and the matrix is HDCP 2.2 and HDCP 1.x compliant. The USB Type-C input adds modern laptop connectivity with up to 60W of power delivery, and the matrix supports up to four USB hosts for KVM control of connected devices, so a single keyboard and mouse can drive multiple sources. It can also supply 48V Power over HDBaseT to a compatible transmitter such as the PUV-2606TX or receiver such as the PUV-2010RX, powering a remote endpoint over the same cable.
Audio is a major strength of the EL-8400VA, which includes multiple analogue stereo inputs, two microphone inputs with switchable 48V or 5V phantom power, and a built-in DSP mixer that can blend any analogue source with the microphone for presentation or lecture use, with the ability to switch instantly between mixed and unmixed audio. A built-in Class-D amplifier delivers 20W per channel to drive speakers directly, alongside balanced stereo line outputs. The unit offers extensive control through front-panel buttons with a volume knob, on-screen display, RS-232, Telnet and WebGUI, plus trigger inputs and relay outputs for room automation. Housed in a full-width 1U enclosure measuring 438mm wide, 44mm high and 270mm deep, the EL-8400VA is TAA compliant and backed by a five year warranty.
What CYP say about the EL-8400VA
The EL-8400VA Presentation Matrix is a multi-format switching matrix with integrated scaling featuring HDMI, DisplayPort, USB Type-C, and HDBaseT I/O. The selected source (video & audio) can be transmitted with HDMI or HDBaseT2 technology over Cat.6A cable up to 100 meters along with bi-directional Ethernet, RS-232, USB, and IR as well as providing 48V PoH power to compatible HDBaseT2 transmitter (PUV-2606TX) and receiver (PUV-2010RX). The HDMI, DisplayPort and USB-C ports support resolutions up to 4K@60 (4:4:4, 8-bit) while the HDBaseT output supports automatic down-conversion of 4K60(4:4:4) sources to 4K60(4:2:0).
Specifications
General
- Brand: CYP
- Model: EL-8400VA
- Product Type: 6x2 Presentation Seamless Matrix with Scaling, USB and Audio
- Switching: Seamless switching
- Scaling: Integrated scaling
- Maximum Resolution: 4K@60Hz 4:4:4 (8-bit) on HDMI / DisplayPort / USB-C; HDBaseT output auto down-converts 4K60 4:4:4 to 4K60 4:2:0
- HDCP: 2.2 and 1.x
- HDBaseT Output: HDBaseT2, up to 100m (Cat6A), with 48V PoH to compatible endpoints
- USB: USB-C (60W power delivery); up to 4 USB hosts; KVM
- Control: Front-panel buttons with volume knob, OSD, RS-232, Telnet, WebGUI, trigger keypad, IP control/LAN
- Compatible Endpoints: PUV-2606TX, PUV-2010RX (alt: PUV-2608TX, PUV-2200PL-TX/RX)
- Certification: TAA Compliant
- Warranty: 5 Year Warranty
Audio
- Audio Mixer: Built-in DSP mixer (blend analogue sources with microphone), switchable mixed/unmixed
- Amplifier: Built-in Class-D, 20W per channel
- Microphone: 2x mic inputs (5-pin Phoenix) with switchable 48V/5V phantom power
- Analogue Inputs: Stereo balanced/unbalanced (5-pin Phoenix), 3.5mm stereo
- Analogue Outputs: 2x stereo balanced/unbalanced (5-pin Phoenix)
- Speaker Output: Speaker-level stereo (2-pin Phoenix)
- Audio Sources: 15 total (10 inputs + 5 mixers)
Connectivity
- Video Inputs: 3x HDMI, 1x DisplayPort, 1x USB-C/Thunderbolt, 1x RJ45 (HDBaseT2)
- Video Outputs: 1x HDMI, 1x RJ45 (HDBaseT2)
- USB: 2x USB 3 Type B hosts (up to 4 hosts total)
- Control I/O: 1x IR I/O (4-pin Phoenix), 8x Trigger Input (10-pin Phoenix), 2x HDBaseT bypass RS-232, 1x IP Control/LAN (RJ45), 2x Dual Relay outputs
- Cable: Cat6A (HDBaseT output, up to 100m)
Power
- Power: Internal IEC PSU
Weight and Dimensions
- Dimensions: 438mm (W) x 44mm (H) x 270mm (D), 1U rack
- Net Weight: 4.1kg
About CYP
CYP's vision is simple, to deliver market-leading connectivity solutions that enhance the capability of Audio Visual products in any installation environment. Continued dedication and focus has made CYP a market leader in connectivity solutions for both systems integrators and professional AV installers throughout Europe. They have a range of over 350 tried and tested products that offer a standard of performance and reliability that cannot be matched.
The key to building such a successful range lies with the ability to continuously develop new products that drive innovation. Within AV distribution this requires an excellent market understanding and the very best R&D engineers. CYP have a continuous new product roadmap containing over 30 projects at any one time, this ensures that they can always provide their partners with innovative application of the very latest technology.
From their European headquarters in Shepperton (UK), they support distributors, systems integrators and installers throughout Europe, the Middle East and Africa. From initial specification of projects through to industry-leading after-sales support and training, they provide their partners with complete confidence in the AV solutions they deliver. Behind this support is a dedicated team of product managers and engineers who all have the skills and experience to deliver practical help at every stage of the CYP journey. It is this passion for the industry and pride in their products that makes them the perfect manufacturer partner.
Specifications
General
- Brand: CYP
- Model: EL-8400VA
- Product Type: 6x2 Presentation Seamless Matrix with Scaling, USB and Audio
- Switching: Seamless switching
- Scaling: Integrated scaling
- Maximum Resolution: 4K@60Hz 4:4:4 (8-bit) on HDMI / DisplayPort / USB-C; HDBaseT output auto down-converts 4K60 4:4:4 to 4K60 4:2:0
- HDCP: 2.2 and 1.x
- HDBaseT Output: HDBaseT2, up to 100m (Cat6A), with 48V PoH to compatible endpoints
- USB: USB-C (60W power delivery); up to 4 USB hosts; KVM
- Control: Front-panel buttons with volume knob, OSD, RS-232, Telnet, WebGUI, trigger keypad, IP control/LAN
- Compatible Endpoints: PUV-2606TX, PUV-2010RX (alt: PUV-2608TX, PUV-2200PL-TX/RX)
- Certification: TAA Compliant
- Warranty: 5 Year Warranty
Audio
- Audio Mixer: Built-in DSP mixer (blend analogue sources with microphone), switchable mixed/unmixed
- Amplifier: Built-in Class-D, 20W per channel
- Microphone: 2x mic inputs (5-pin Phoenix) with switchable 48V/5V phantom power
- Analogue Inputs: Stereo balanced/unbalanced (5-pin Phoenix), 3.5mm stereo
- Analogue Outputs: 2x stereo balanced/unbalanced (5-pin Phoenix)
- Speaker Output: Speaker-level stereo (2-pin Phoenix)
- Audio Sources: 15 total (10 inputs + 5 mixers)
Connectivity
- Video Inputs: 3x HDMI, 1x DisplayPort, 1x USB-C/Thunderbolt, 1x RJ45 (HDBaseT2)
- Video Outputs: 1x HDMI, 1x RJ45 (HDBaseT2)
- USB: 2x USB 3 Type B hosts (up to 4 hosts total)
- Control I/O: 1x IR I/O (4-pin Phoenix), 8x Trigger Input (10-pin Phoenix), 2x HDBaseT bypass RS-232, 1x IP Control/LAN (RJ45), 2x Dual Relay outputs
- Cable: Cat6A (HDBaseT output, up to 100m)
Power
- Power: Internal IEC PSU
Weight and Dimensions
- Dimensions: 438mm (W) x 44mm (H) x 270mm (D), 1U rack
- Net Weight: 4.1kg
