PUV-1630TXWP-EU – HDBaseT1 switching Wallplate Transmitter (EU version) for the Reverse Power PUV-1600 Series
The CYP PUV-1630TXWP-EU is an EU wall-plate HDBaseT transmitter that turns a wall outlet into a tidy, multi-input connection point for a source room, sending video, audio, network and control to a remote display over a single Cat5e, Cat6 or Cat7 cable. It accepts two HDMI sources and one VGA source and automatically switches between them, so a presenter can simply plug in a laptop or media player and start sharing without touching a control system. As part of CYP's reverse-power PUV-1600 series, the plate is powered from the receiver end, which keeps installation clean where there is no spare power behind the wall.
Auto-switching uses hot-plug detection to select whichever input has just been connected, giving genuinely hands-free operation, while a built-in scaler automatically converts higher-bandwidth sources so that any HDMI 4K UHD signal is passed reliably across the HDBaseT link, down-converting 4K@50/60Hz to 4K@30Hz 4:4:4 to suit the 10.2Gbps HDBaseT bandwidth, and it supports VGA resolutions up to WUXGA. The unit is HDMI 2.0 compatible and HDCP 2.2 compliant, and a 3.5mm analogue audio input lets local audio be embedded into the stream. A LAN connection is carried over the same cable, and CEC control, programmed through the built-in Web GUI, can power up the connected display and select the correct HDMI input, with front-panel push-button control and LED indicators for input, link and power status.
The selected source travels up to 100 metres over structured cabling to a compatible PUV-1600 series receiver such as the PUV-1610RX, which also supplies power back to the plate over the same cable using Power over HDBaseT. Housed in an EU-standard wall-plate form factor measuring 152mm wide, 81mm high and 42mm deep, the PUV-1630TXWP-EU sits flush in the wall for a discreet, professional finish. It is TAA compliant, suiting public sector and government procurement requirements, and is backed by a five year warranty.
What CYP say about the PUV-1630TXWP-EU
The PUV-1630TXWP Transmitter is a 2 x HDMI, 1 x VGA switch which allows uncompressed HDMI and VGA signals to be transmitted over a Single CAT5e/6/7 cable. This solution has the added features of analogue audio embedding and a LAN connection over the same CAT5e/6/7 cable. These combined HDMI and control signals can be transmitted up to lengths of 100 metres to a compatible PUV-1600 Series Receiver. When a device is connected to the PUV-1630TXWP, CEC control can be applied to 'power up' the connected display and select the correct HDMI input channel (programmed via the Web GUI).
Specifications
General
- Brand: CYP
- Model: PUV-1630TXWP-EU
- Product Type: EU Wall-Plate HDBaseT Switching Transmitter (2x HDMI + 1x VGA)
- Series: Reverse Power PUV-1600 Series
- Extension Standard: HDBaseT1
- Video Compatibility: HDMI 2.0
- Maximum Resolution: 4K@30Hz 4:4:4 over HDBaseT (accepts 4K@50/60Hz, auto-converts to 4K@30Hz 4:4:4)
- VGA Support: Up to WUXGA
- HDCP: 2.2
- Extension Distance: Up to 100m (Cat5e/6/7)
- Switching: Auto-switching between HDMI and VGA (hot-plug detection), front-panel push-button
- Scaling: Automatic conversion of higher-bandwidth sources for HDBaseT
- Control: CEC (display power-up and HDMI input selection, via Web GUI)
- Status Indicators: LEDs for input, link and power
- Certification: TAA Compliant
- Warranty: 5 Year Warranty
Audio
- Analogue Audio: 3.5mm stereo (L/R) input, embedded into the HDBaseT stream
Connectivity
- Inputs: 2x HDMI, 1x VGA (15-pin D-Sub RGBHV), 1x 3.5mm (analogue audio), 1x RJ45 (LAN)
- Output: 1x RJ45 (HDBaseT)
- Cable: Single Cat5e/6/7
Power
- Power: PoH (Power over HDBaseT) from a compatible PUV-1600 series receiver (reverse power)
Weight and Dimensions
- Dimensions: 152mm (W) x 81mm (H) x 42mm (D), EU wall-plate form factor
- Net Weight: 260g
