Ferrum Audio BROEN network streaming transport
The Ferrum BROEN is a network streaming transport built around a clear engineering philosophy: take a stream of digital audio data and keep it as clean and accurate as possible from the moment it enters the unit to the moment it leaves. At the heart of the design is the SERCE DDC, a proprietary digital-to-digital conversion module with FPGA-based reclocking and ultra-low jitter audio clocks on all synchronous outputs. The input and output domains are kept entirely separate throughout, and all audio outputs sit behind a galvanic isolation barrier, covering both the synchronous outputs and the dedicated USB DAC connections. The result is a transport that delivers a genuinely quiet and stable digital signal regardless of what is happening on the network side of the device.
Streaming capability is handled by Volumio, a platform with a broad and well-established ecosystem supporting Spotify Connect, TIDAL Connect, Qobuz Connect, AirPlay, UPnP/DLNA, Bluetooth, web radio, and multi-room playback across up to six synchronised zones. Music can be played from an internal M.2 NVMe SSD slot, USB drives, or a NAS, and CD playback and ripping are also supported. Network connectivity covers dual-band Wi-Fi as standard, with an SFP socket allowing the addition of either a standard RJ45 ethernet module or a fibre optic module for those who want to keep electrical noise from the network entirely out of the signal path. Over-the-air firmware updates keep the platform current.
Audio outputs cover AES/EBU, S/PDIF coaxial, S/PDIF optical, I2S via HDMI with configurable pinout, and two dedicated USB DAC outputs via Type-A and Type-C. The BROEN integrates directly with the Ferrum WANDLA DAC via Ferrum Streaming Control Technology, displaying track information on the WANDLA's screen and allowing full playback control through its touchscreen and remote. Performance can be taken further still by adding the Ferrum HYPSOS power supply, which connects via the proprietary Ferrum Power Link cable to deliver optimised, voltage-sensed power to both components simultaneously.
What Ferrum Audio say about the BROEN Network Streaming Transport
With BROEN we have created a truly unique streaming proposition following all of Ferrum’s core values. Like we did with HYPSOS, BROEN’s design starts at the very beginning of any digital transport, a sequence of zeros and ones and keeps it as clean as it possibly can. From beginning to end.
This meant going back to the digital drawing board and create a new digital heart for BROEN, called SERCE DDC. While keeping the in- and output domains perfectly separated and the audio outputs isolated, we also introduced an SFP socket to give our community the ultimate choice in digital connectivity, offering wireless as standard, plus electrical (RJ45 ethernet) and optical (SFP) options for communication with the home network. Supporting the most relevant streaming options, we also offer an internal SSD slot for physical storage of your music files. Last but not least BROEN is expandable with WANDLA to create the ultimate streaming DAC combo and upgradable with HYPSOS. WANDLA like a Formula 1 racing car. Like the F1 constructor’s team building the best racing car, Ferrum created the best engine for The Converter.
Made for Streaming
BROEN is Powered by Volumio. This means you get full access to the Volumio streaming ecosystem, loved by more than half a million users, with Spotify & Spotify Connect, TIDAL & TIDAL Connect, Qobuz & Qobuz Connect, AirPlay, UPnP/DLNA renderer, web radios, CD playback, multi-room playback, AI-powered SuperSearch, Infinity Playback, and extended album/artist metadata.
Made for WANDLA
While you can control BROEN perfectly from your smartphone, tablet and computer, BROEN seamlessly integrates with WANDLA using our FSCT. Artist and title information will be displayed on WANDLA’s screen and can be controlled with a finger’s touch on WANDLA’s screen or remote.
Made for HYPSOS
BROEN performs beautifully right out of the box, but you can take its performance above and beyond when pairing it with HYPSOS. Using the proprietary Ferrum Power Link (FPL) connection with 4TSD voltage sensing, both components will perform to their absolute maximum, unleashing unheard-of musicality.
Made for the Future
With BROEN you get over-the-air (OTA) firmware updates, and a plugin capable platform. Apart from including an internal SSD slot, we’ve added an SFP slot where you have the option of using a standard SFP ethernet module or an SFP optical module to connect to an SFP switch keeping noise to an absolute minimum when connecting to the outside world. These features will keep BROEN up to date and future proof for many more years to come.
Specifications
Streaming and Playback
- Platform: Powered by Volumio
- Control: iOS/Android app, any web browser, or front-panel buttons
- Supported Formats: MP3, WMA, AAC, ALAC, FLAC, APE, WAV, DSD
- Streaming Services: Spotify and Spotify Connect, TIDAL and TIDAL Connect, Qobuz and Qobuz Connect
- AirPlay via Shairport Sync
- UPnP/DLNA renderer
- Integrated web radio directories
- CD playback and ripping
- Bluetooth A2DP playback
- Streaming to Sonos and Chromecast
- Playback from USB drives, internal M.2 NVMe SSD, or NAS (DLNA)
- Multi-room playback (up to 6 synchronized zones)
- AI-powered SuperSearch and Infinity Playback
- Extended album and artist metadata
- Multi-language support (29 languages)
- Alarm and sleep function
Audio Outputs
- S/PDIF Coaxial
- AES/EBU
- S/PDIF Optical
- I2S (HDMI, configurable pinout)
- 2x Dedicated USB DAC outputs (Type-A and Type-C)
Network and Connectivity
- Dual-band Wi-Fi (2.4GHz and 5GHz) included as standard
- SFP socket for optional RJ45 ethernet or fibre optic modules (not included)
- Hotspot mode for first-time setup
- 2x USB 3.0 (Type-A and Type-C) for media drives and service
- Internal M.2 NVMe SSD slot (user-supplied, 80mm or 110mm; drive not included)
- HDMI video output for screen display and system interface
Design and Performance
- Output Stage: SERCE DDC module with FPGA-based reclocking
- Ultra-low jitter audio clocks on synchronous outputs (Coaxial, Optical, AES, I2S)
- Galvanic isolation on all audio outputs
- Separated input and output signal domains
- Dedicated clean VBUS power supply for USB DAC output
Integration and Compatibility
- Ferrum Streaming Control Technology (FSCT) support
- Trigger In and Trigger Out
- Compatible with Ferrum WANDLA and ERCO DACs
- Compatible with third-party DACs
- Upgradable with Ferrum HYPSOS power supply via Ferrum Power Link (FPL)
- Over-the-air (OTA) firmware updates
Weight and Dimensions
- Dimensions: 217 x 206 x 50mm (8.6 x 8.1 x 2.0 inches) W x D x H
- Weight: 1.90kg (4.19 lbs)
About Ferrum
Polish maker of DACs, headphone amplifiers and linear power supplies, designed and built in Warsaw.
Ferrum Audio is based in Warsaw, Poland, where its parent company designs and manufactures its products in-house. The range is built around the Wandla DAC and pre-amplifier, the OOR headphone amplifier and the Hypsos power supply, along with the power cables and splitter that connect them. You can build a compact system from these parts.
