Ortofon 2M Mono Hi-Fi Turntable Cartridge
£459.00 £382.50
SKU
2M Mono
Free UK Delivery
12 Months
New
24 hours
Ortofon's 2M Mono uses a nude spherical diamond as an optimal solution to playback mono microgroove LP vinyl records. By utilising Ortofon's strapped output, both pole pins within the cartridge deliver the same output signal, resulting in a truly mono reproduction possible through any stereo playback system.
Ortofon 2M Mono Hi-Fi Turntable Cartridge
Ortofon's 2M Mono uses a nude spherical diamond as an optimal solution to playback mono microgroove LP vinyl records. By utilising Ortofon's strapped output, both pole pins within the cartridge deliver the same output signal, resulting in a truly mono reproduction possible through any stereo playback system.
Each of the 2M Series cartridges has its own individual sonic expression, and all five models together represent the ensemble of five classic variations. 2M Mono SE, 2M Mono and 2M 78 are a true mono cartridges for playing mono vinyl records
The 2M series of cartridges feature Ortofon’s trademark split pole pins, an invention that enables moving magnet cartridges to have a flat frequency response, as with a moving coil cartridge. Split pole pins were invented by Ortofon, and were originally presented in the 500 series and OM Super series.
Features
- Optimised sound reproduction and high level of sonic accuracy
- R 18µm Nude Spherical stylus that is an optimal solution for playing mono microgroove LP vinyl records
- Uses a strapped output to deliver the same output signal from both sets of pole pins
- Supplied with 2 different sets of screws (M2.5 x 5 & M2.5 x 7)
- Carbon fibre stylus brush and tracking force gauge included
The story behind the 2M series
The 2M Series was developed in conjunction with the Danish designer Moeller Jensen Design. Inspired by the facets of a diamond, whose contours gracefully trace the grooves on a record’s surface, the 2M’s handsome elegance establishes a great combination of form and functionality. Of course, the 2M isn’t just another pretty face. It has been engineered to the highest standards and is congruent with Ortofon’s unrelenting commitment to providing the most precise and accurate reproduction possible without colouration.
The name “2M” was chosen as it represents the abbreviation for moving magnet, MM.
The four-model 2M line was originally introduced in 2008, and since then the range has been extended to include True-mono models 2M MONO and 78. Also available are models with expanded mounting options, such as Verso for bottom mount headshells and PnP for direct mounting on arms with universal mount.
Styli interchangeability
2M Series styli are engineered for a tight fit to minimize coupled vibrations, thereby improving sound reproduction. Physically 2M styli will fit on alternative 2M cartridges bodies, but 2M Series cartridges’ engines, coils and magnets configurations are not quite identical: Red and Blue are identical, so are the Bronze and Black and so are the true mono variants 2M Mono and 2M 78.
Styli lifetime and care
With proper care, Ortofon finds that up to 1,000 hours is possible without degradation of performance. The stylus does begin to exhibit changes after 1,000 hours, but the stylus life as a whole is expected to top 2,000 hours. Proper care is comprised of the following:
- Cleaning of record by means of fibre brush before and after every use
- Cleaning of record by using a record cleaning machine once in a while
- Cleaning of the stylus by means of a fine antistatic brush. Please remember to remove dust from the diamond tip before and after playback of each record. Use the brush in the forward direction from the rear of the cartridge towards the stylus tip, never from stylus tip to the rear of the cartridge and never from side to side
- Proper adjustment of alignment, anti-skating, azimuth and tracking force
- Ortofon does not recommend the use of solvents of any kind for cleaning of either record surface or stylus.
|
|
|
"The 2M mono felt quite direct, with a solidity to the heavier struck notes that reflected their impact. Softer sounds were floated towards me, leaving me impressed with this cartridge’s ability to swing from soft to loud and back again without fuss. Hi-Fi World - August 2013
|
Specification
- Output voltage at 1 kHz, 5cm/sec: 4 mV
- Frequency range at -3 dB: 20 - 22,000 Hz
- Frequency response: 20 - 20,000 Hz +3/-1 dB
- Tracking ability at 315 Hz at recommended tracking force: 70 μm
- Compliance, dynamic, lateral: 18 μm/mN
- Stylus type: Nude Spherical
- Stylus tip radius: r/R 18 μm
- Tracking force range: 1.6 - 2.0 g (16 - 20 mN)
- Tracking force recommended: 1.8 g (18mN)
- Tracking angle: 20°
- Internal impedance, DC resistance: 0.7 kOhm
- Internal inductance: 350 mH
- Recommended load resistance: 47 kOhm
- Recommended load capacitance: 150 - 300 pF
- Cartridge colour, body/stylus: Black/White
- Weight: 7.2 g
- Dimensions: 24mm x 18.5mm x 18mm
About Ortofon
Ortofon is one of the world leader's in the development and manufacturing of turntable cartridges. The wealth of knowledge and expertise at Ortofon has been accumulating since 1918 with their first moving coil cartridge manufactured in 1948.
Today, Ortofon offers a wide range of cartridges for both DJ's and Hi-Fi audiophiles. Their offering includes moving magnets, moving coils, plug-and-play headshells, mono cartridges and 78RPM cartridges.
Throughout their range of cartridges, Ortofon maintains a set profile with each cartridge profile containing an individual sonic expression. All of Ortofon's range of cartridges includes a Red, Blue, Bronze and Black model.
First, in the range, are the Red cartridges which deliver open, dynamic sound with a slight touch of warmth. Next, the Blue Cartridges offer greater dynamic soundstages with improved detail and resolution. Following on, the Bronze cartridges improve the details in a way that pays respects to all elements of the track. Lastly, the Black cartridges are the best at everything. They are true to the groove with resolution and accurate insight into each recording.
Ortofon have made their cartridges suitable for the majority of turntables on the market at the moment. With a wide range of available models, there is an Ortofon cartridge to suit everyone.
Specification
- Output voltage at 1 kHz, 5cm/sec: 4 mV
- Frequency range at -3 dB: 20 - 22,000 Hz
- Frequency response: 20 - 20,000 Hz +3/-1 dB
- Tracking ability at 315 Hz at recommended tracking force: 70 μm
- Compliance, dynamic, lateral: 18 μm/mN
- Stylus type: Nude Spherical
- Stylus tip radius: r/R 18 μm
- Tracking force range: 1.6 - 2.0 g (16 - 20 mN)
- Tracking force recommended: 1.8 g (18mN)
- Tracking angle: 20°
- Internal impedance, DC resistance: 0.7 kOhm
- Internal inductance: 350 mH
- Recommended load resistance: 47 kOhm
- Recommended load capacitance: 150 - 300 pF
- Cartridge colour, body/stylus: Black/White
- Weight: 7.2 g
- Dimensions: 24mm x 18.5mm x 18mm
