SEADA SC-DPH Series DP 1.4 to HDMI 2.0
The SC-DPH Series Active Optical Cables (AOC) from SEADA delivers high-performance DisplayPort to HDMI conversion for demanding AV applications. These cables support transmission of HDMI signals at up to 4K resolution, 60 frames per second, and 4:4:4 chroma subsampling at 18Gbps, reaching distances of up to 60 meters without compression.
Engineered with a hybrid design that combines fiber optics and copper wire, the SC-DPH Series significantly reduces vulnerability to electromagnetic interference, ensuring stable and clear audio-video delivery even in challenging environments. The built-in booster circuit is powered directly through the DisplayPort interface, eliminating the need for external power supplies.
Available in lengths ranging from 10 to 60 meters, these cables offer flexible installation options for a wide range of applications, including home entertainment systems, corporate AV setups, gaming stations, medical displays, conference rooms, and digital signage.
Whether you're setting up in a residential or commercial space, the SC-DPH Series HDMI AOC provides a reliable, plug-and-play solution for transmitting ultra-high-definition video and audio over long distances.
SC-DPH Series DP 1.4 to HDMI 2.0
These SC-DPH Series Active Optical Cables (AOC) from SEADA can take a Display video input and convert it to HDMI signal and then tranmit this HDMI signal up to 4K@60fps 4:4:4 at 18Gbps data rate up to 60 meters without any compression. Comprised of a fiber and traditional copper wire cable, this active cable is less susceptible to EMI interference, for a clear and reliable audio/Video signal.
Key Features
- Low power consumption, no external power supply needed
- Thinner (cable OD 4.5mm), lighter and softer than the normal copper cable
- Self-conversion from DisplayPort signal to HDMI signal
- Compatible with HDMI 2.0 standard
- Unique internal cabling comprising OM3 multimode optical fibre and copper with pliable PVC sleeve
- Long distance transmission up to 60 meters
- Employs VCSEL LED emitters for accurate signal transmission
- Superior transfer rates, up to 18Gb/s @60Hz ideal for 4K
- Compatible with all versions of HDCP up to 2.2
- Plug & Play no driver required
- RF screening to prevent interference
Specifications
- Cable Diameter: 4.5mm
- Bend Radius (Dynamic/Static): 40mm/20mm
- Tensile Strength @ Long term: 100N
- Tensile Strength @ Short term: 200N
- Crush Resistance @ Long term: 200N
- Crush Resistance @ Short term: 400N
- Cable configuration: 4*Fiber + 7*cooper + PVC Jacket
- Fiber Module: 50/125 um
- Transducer: 4 CH 850nm VCSEL/PIN
- Working current: ≤45mA
- Power Consumption: ≤250mw
- Finished OD: 5.5±0.1mm
- HDMI Connector: Type A
- Total Bandwidth: 18 Gbps
- Operating Temperature Range: 0~50 degrees centigrade
- Operating Humidity Range: 10%-90% non-condensing
- Storage Temperature Range: -20~70 degrees centigrade
- Storage Humidity Range: 10%~90% non-condensing
- Warranty: 2 Years
