Van Den Hul The MC-Silver IT MKII 75 Ohm Digital Cable
As low as £950.00 £791.67
SKU
Van Den Hul The MC-Silver IT MKII 75 Ohm
12 Months
New
24 hours
Regarding its extremely high bandwidth (GHz range) and extremely low attenuation it would certainly apply
Van Den Hul The MC-Silver IT MKII 75 Ohm Digital Cable
With there (now discontinued) highly acclaimed The MC-Silver IT MKII Coaxial in steady demand since its introduction in 1982, an often heard question was whether it could yield likewise improvements in perceived quality when used as a high frequency link to transport 75 Ohm radio, TV, video and even SPDIF (consumer format) digital audio.
Regarding its extremely high bandwidth (GHz range) and extremely low attenuation it would certainly apply. However, since the characteristic impedance of our MC - The MC-Silver IT MKII Coaxial is a very constant 60 Ohms we have always advised against such usage: its impedance mismatch in equipment designed for 75 Ohm signal transport would cause transmission quality degrading signal reflections.
We therefore have decided to introduce there MC-Silver IT MKII 75 Ohm:
Features:
- This cable is specially adapted to maximum quality 75 Ohm signal transport as found in SPDIF digital audio (CD to DAC) and radio / TV / video (including home theater) applications. However, since the design of this cable only slightly differs from our (now discontinued) MC-Silver IT MKII Coaxial and employs the same high grade materials, the MC-Silver IT MKII Mk II 75 Ohm is equally well suited to be used in high quality audio applications as a single-ended (unbalanced) interlink as our MC-Silver IT MKII Coaxial is.
- Also available with RCA type connectors, The MC-Silver IT MKII75 Ohm now fully replaces our discontinued MC-Silver IT MKII Coaxial in high quality audio applications as a single-ended (unbalanced) interlink. With the MC-Silver IT MKII Mk II 75 Ohm all production handling is done with extreme care and maximum attention is paid to maintain a very constant characteristic impedance along the whole cable as well as in the micro domain to prevent signal reflections even up to very high frequencies.
- The centre lead consists of a 19 strand extreme high grade Matched Crystal (MC) extruded OFC with a very high density extruded Matched Crystal (MC) purest silver coating applied in a mechanical processing.
- The diameter of this centre conductor is: 1.0 mm. and the cross-section area is 0.597 mm². The centre lead resistance is a remarkably low: 28.7 Ohm/km.
- The typical capacitance is: 56 pF/meter.
- The insulation between core and shielding is made of Teflon tape in several layers with a typically low relative dielectric constant of 1.4.
- The shielding is made of a helical wound very pure silver ribbon with external dimensions 2.5 x 0.05 mm.
- An additional braiding made of 192 x 0.10 mm. Matched Crystal (MC) OFC wires with a very dense coating of very pure silver is used.
- The external insulation is made of a special type of HULLIFLEX ®, i.e. HULLIFLEX ® EHD. This specific insulation material is too costly to be used in all our products.
- The frequency range is flat to minimal 15 GHz and within 0.92 dB/meter attenuation even up to 21 GHz. And even at 25 GHz the attenuation is just 1.04 dB/meter.
- The working temperature ranges from -100 to +80 °C (-148 to +176 °F).
- Precaution must be taken to prevent bending over a very small radius. The minimum safe value of the bending radius is 70 mm.
- The external diameter of the MC - SILVER IT Mk II 75 Ohm is: 7.0 mm.; a size that perfectly matches our C - 7.3 RCA type and BNC - 7.0 BNC type connectors.
Specification:
- Van Den Hul The MC-Silver IT MKII 75 Ohm (Halogen Free) Digital Audio Cable
- Material: Silver
- Cable type: Coaxial
- Conductor material: Strands with a thin high purity Matched Crystal OFC core and a thick high purity dense Matched Crystal Silver layer; Screen includes a high purity Matched Crystal Silver ribbon
- Design purpose: Highest quality level 75 Ohm HF applications, SPDIF digital interconnect and high quality audio applications
- Eff conductor Core: 0.597 mm² / Core: AWG 19.4 / Core: 19; Screen: 192 + Ag tape
- External diameter: 7.0 mm
- Jacket colours: Transparent cobalt blue, (Earlier versions: transparent white)
- Resistance Core: 2.87 Ohm/100 m.; Screen: 0.770 Ohm/100 m. capacitance 56 pF/m
- Characteristic impedance: 75 Ohm
- Insulation Core: PTFE tape; Jacket: HULLIFLEX ® EHD / 300 Vrms min
- Connector types: There BNC type BNC - 7.0 and there RCA type C - 7.3;
- Remarks: In the MC - SILVER series are also available: The MC - SILVER IT 65 G, The MC - SILVER IT Mk II Balanced and The MC - SILVER IT Mk III Balanced.
- Warranty: 12 Months Warranty
Specification:
- Van Den Hul The MC-Silver IT MKII 75 Ohm (Halogen Free) Digital Audio Cable
- Length: 0.6m
- Material: Silver
- Cable type: Coaxial
- Conductor material: Strands with a thin high purity Matched Crystal OFC core and a thick high purity dense Matched Crystal Silver layer; Screen includes a high purity Matched Crystal Silver ribbon
- Design purpose: Highest quality level 75 Ohm HF applications, SPDIF digital interconnect and high quality audio applications
- Eff conductor Core: 0.597 mm² / Core: AWG 19.4 / Core: 19; Screen: 192 + Ag tape
- External diameter: 7.0 mm
- Jacket colours: Transparent cobalt blue, (Earlier versions: transparent white)
- Resistance Core: 2.87 Ohm/100 m.; Screen: 0.770 Ohm/100 m. capacitance 56 pF/m
- Characteristic impedance: 75 Ohm
- Insulation Core: PTFE tape; Jacket: HULLIFLEX ® EHD / 300 Vrms min
- Connector types: There BNC type BNC - 7.0 and there RCA type C - 7.3;
- Remarks: In the MC - SILVER series are also available: The MC - SILVER IT 65 G, The MC - SILVER IT Mk II Balanced and The MC - SILVER IT Mk III Balanced.
- Warranty: 12 Months Warranty
