Atlas Arran Transpose Speaker Jumper Links - Pack of 4
£950.00 £791.67
SKU
Arran Speaker Jumper Links
Free UK Delivery
5 Years
New
48 Hours
Atlas have been working tirelessly to create a new range of cables that can offer the exceptional performance levels of the Asimi range, however, utilising their expertise in OCC Copper to deliver a more natural, open sound profile. Enter the Arran cable. With 6 solid OCC Copper conductors, a helical cotton spiral/PTFE dielectric, and double screened dual drain system, the Atlas Arran cables offer the best of Atlas' cable technology at an excellent value for money.
Related Products
Atlas Arran Transpose Speaker Jumper Links - Pack of 4
The Atlas Arran Transpose Speaker Jumper Links, available in a pack of four, are a cutting-edge audio product designed for discerning audiophiles seeking the highest level of performance.
The Transpose Modular Speaker Connector is a unique feature that allows for the easy adjustment of the links, ensuring optimal signal transfer between the amplifier and the speaker. The OCC Copper Conductors and PTFE Dielectric offer superior signal transfer, ensuring a clean and accurate audio signal. The Solid Core Construction is designed to minimise signal loss and distortion for a pure and natural sound.
The Atlas Arran Transpose Speaker Jumper Links are an excellent choice for anyone seeking to upgrade their audio system with a premium quality product that delivers exceptional performance. With its advanced features and superior construction, this product offers a high level of value for money and is sure to satisfy even the most discerning audiophile. With 6 solid OCC Copper conductors, a helical cotton spiral/PTFE dielectric, and a double-screened dual drain system, the Atlas Arran cables offer the best of Atlas' cable technology at an excellent value for money.
Features :
- Transpose Modular Speaker Connector
- OCC Copper Conductors
- PTFE Dielectric
- Solid Core Construction
- Grun Coherent Earthing System
Transpose Modular Speaker Connector
The Transpose is a modular, cold-weld, air-tight, solder-free speaker plug. Interchangeable connector options are spade, Z-plug and expanding plug, available in gold or silver.
In a cold-weld connection, the metal of the connector plug and the wire are squeezed together under a calibrated pressure to form a robust, consistent, air-tight metal-to-metal contact with no damage to the cable dielectric. The result is a smooth, uninterrupted signal path that behaves as one continuous entity, with minimal signal degradation compared to soldered connections.
Ohno Continuous Casting Copper (OCC Copper)
The Ohno continuous casting method re-heats the extrusion as the molten copper is forced out of the mould and very slowly and gradually draws the grain or crystal down the conductor''s length, creating a ‘single crystal structure.’ Actually, because no copper is 100% pure, there will always be a few boundaries produced by impurities. The frequency of boundaries created are quite insignificant. A typical crystal in a copper conductor drawn to 0.3 mm diam. using the OCC process is 125.00 metres long!
The benefits are obvious, with almost no crystal boundaries, the audio signal is no longer impeded down the copper wire and more information and detail is delivered faithfully to the receiving equipment.
| Copper Purity Comparison (0.3mm Diameter) | ||||
| TPC | OFC | OCC | ||
| Purity | >99.9% | >99.99% | >99.999% | |
| Specific Gravity | 8.75 | 8.926 | 8.938 | |
| Gas Impurities (ppm) | ||||
| O2 | 200~500 | <10 | <5 | |
| H2 | <0.5 | <0.5 | <0.3 | |
| Average Crystal Size (Metre) | 0.007 | 0.02 | 125.00 | |
| Crystals Per Metre | 150 | 50 | 0.008 | |
PTFE Dielectric
PVC (Poly Vinyl Chloride) is cheap to produce and, as such, is the most commonly used insulation in AV cables. However, PVC is the worst quality insulation a Hi-Fi or AV signal can encounter as its high loss causes a significant reduction in signal velocity. PVC is better suited to power cables and should be avoided in Hi-Fi and AV signal cables.
Other dielectrics in common use are Polyethylene, Polypropylene and Polytetrafluoride Epoxy (better known as PTFE (Teflon™) or Teflon,) and the new and unique Atlas (PTFE).
Microporous PTFE (Teflon™) is a unique, low density dielectric material, phase stable at room temperature, which offers significant performance improvements over solid PTFE (Teflon™) dielectric designs.
The table below shows the properties of a selection of dielectrics. Though not used as a dielectric in Atlas' cables, PVC is included for comparison purposes.
| Dielectric Material Comparison (0.3mm Diameter) | |||||
| Property | Polyvinyl Chloride (PVC) |
Foamed Polyethylene (PEF) |
Polypropylene (P.P) |
Teflon (FEP or PTFE) |
PTFE |
| Dielectric Constant (@ 50 -106Hz) |
4-8 | 2.3 | 2.25 | 2.1 | 1.3 |
| Dielectric Strength (kV mm-1) |
23-30 | 30-50 | 30-50 | 20-25 | N/A |
| Loss Tangent (% @ 50 - 106Hz) |
8-15 | 0.02-0.05 | 0.02-0.06 (@ 106Hz) |
0.02-0.07 | N/A |
| Volume Resistivity (Ohms.cm @ 20°C) |
1012-15 | >1017 | 6.5x1014 | >1016 | N/A |
| Tensile Strength (Kg mm-2) |
1.0-2.5 | 1.0-2.0 | 3.0-4.0 | 1.9-2.2 | 1.0 |
| Melting Point (°C) |
-130 | 112-120 | 155-160 | 275 | 275 |
| Max. Continuous Operating Temp. (°C) |
60 | 75 | 90 | 200 | 260 |
| Min. Operating Temp. (°C) |
-15 to -40 | <-60 | -5 to -45 | <-60 | -250 |
Grun Coherent Earthing System
One of the biggest obstacles to achieving the performance levels our equipment is capable of is noise. Low levels of RFI (radio frequency) and EMI (electro-magnetic interference) and noise on the signal ground all subtly modulate and degrade the overall noise levels of the system.
Ironically, this is generally only noticeable when eliminated – even though much of this ‘noise’ is theoretically at frequencies beyond the range of our hearing. The main sources are noise in the mains supply and component ground connections – mobile phones, ‘wallwart’ chargers and wifi networks are major offenders – while a percentage is actually generated within the equipment itself. Generally things have got worse with the advent of computer audio.
The Grun Coherent Earthing System addresses these issues by providing an ‘independent’ earth for users of Mavros and Asimi Ultra interconnects and Mavros Speaker cables with the new Grun configuration.
|
|
|
"After auditioning the Arran interconnects and loudspeaker cables in three different setups, it’s evident these products are aimed at purists already satisfied with the balance of their carefully curated components and in search of wiring that allows the true potential of their system to be heard with minimal loss of fidelity." (Read More) The Ear - 5 Star Review - November 2022
|
Specification:
- Conductors: 6 Solid-Core OCC Copper
- Dielectric: PTFE + Helical Cotton Spiral
- Plugs: Transpose Deep Silver-Plated Plugs; Expanding, Z or Spade
- Warranty: 5 Years
About Atlas Cables
Atlas Cables are a major producer of interconnects and cables in the United Kingdom of Great Britain. All products are researched, developed and most are assembled in the Atlas purpose built factory in Scotland.
Many of these products are unique and use advanced techniques of production or manufacture in order to bring to the user the very finest quality products. With each new model we continue to push the boundaries of reliability and performance. It's little wonder then, that Atlas Cables have had so many mile-stone advances in the past and that Atlas Cables have secured so many awards in comparative tests against other products.
Specification :
- Conductors: 6 Solid-Core OCC Copper
- Dielectric: PTFE + Helical Cotton Spiral
- Plugs: Transpose Deep Silver-Plated Plugs; Expanding, Z or Spade
- Warranty: 5 Years
