Atlas Hyper DD Achromatic 3.5mm to RCA Digital Audio 1m Cable - Ex Demo

£142.50 Special Price £128.25 £106.87
SKU
Hyper DD Achromatic Digital Audio Ex Demo
Free UK Delivery
5 Years
EX-Demo
24 hours
what's this?

We can burn-in your cable for up to 96 hours FREE of charge using our Nordost VIDAR cable burner. This is a £3000 machine that will optimise the performance of your cables from day one. This means the cables will be in optimum performance mode when you receive them, so you'll be able to make a performance assessment quickly rather than waiting 70 hours+ of usage. The result of conditioning cables with the Nordost VIDAR is, improved sound staging, increased detail, and an overall more musical presentation. Please Note: we are unable to burn-in cables with stripped bare ends, BFA-only plugs, or no plugs selected. (This does not apply to BFA/Banana plugs). Cables are burnt-in for the selected period AFTER your order has been processed. This service is offered at Future Shop's discretion and we cannot guarantee all burn-in requests are fully completed during busy periods.

what's this?
SPEAKER CABLES:

A quantity of 2 means you will receive a pair of speaker cables e.g. for your front left and front right speakers. By entering a quantity of 1, you will get a cable for a single speaker e.g. centre speaker and this option also enables you to vary the length (and termination) of your cable for each speaker.

OTHER CABLES:

A quantity of 1 means you will receive a single cable in the case of aerial, satellite, subwoofer, digital coaxial & optical cables and a pair of cables in the case of 2 rca to 2 rca analogue audio cables.

NON-CABLE PRODUCTS:

A quantity of 1 means you will receive 1 of the specified products.

Available

Need help? Call us on 0800 772 3688 or 0208 905 1555

Prefer email? Contact us via sales@futureshop.co.uk

A 75 Ohm digital cable designed to perfectly complement Atlas' acclaimed Hyper Achromatic and Hyper DD Ultra RCA interconnects.

Atlas Hyper DD Achromatic 3.5mm to RCA Digital Audio 1m Cable - Ex Demo



The Hyper Achromatic RCA S/PDIF is designed to match the consumer digital audio specification by maintaining a true 75 Ohm impedance, ensure error-free transmission of digital data signals. Many cables actually fail to meet the 75 Ohm standard due to flaws in the way the cable itself is manufactured and assembled. Atlas' cold-weld solder-free connectors avoid the continuity breaks and compression of the cable’s shielding screen which cause impedance problems and lead to compromised jitter performance.

The Hyper DD Achromatic Digital Audio cable benefits from a simplified version of the dual-drain system originally developed for our top-of-the-range Mavros and Asimi interconnects. Twin symmetrical drain wires connect the screen to the cable return/plug interface, meaning the cable can be terminated without distorting, twisting or mechanically stressing the precision-laid screen. The benefits are in maintaining a consistent low impedance load to the plug, and a total 360° screening against noise and signal loss caused by RFI (Radio Frequency Interference).

The Hyper dd Achromatic RCA is a superior digital cable for connecting a CD transport or streamer to a DAC.



Features :

  • Achromatic RCA Plugs
  • OCC Copper Conductors
  • PEF Dielectric
  • Coax Construction

Achromatic Plugs

Atlas’s expert electro-mechanical knowledge has led to the innovation of the next generation of RCA plugs. Known as the ‘Atlas Achromatic RCA plug’, Atlas has focused on improving both performance and appearance to create a higher performance starting point for their RCA cables as well as eliminating variability in performance. This has been achieved by refocusing on materials and the assembly processes.

Atlas has made 4 key changes with the Achromatic RCA plug. Firstly, the barrel of the Achromatic plug features a high stability ABS material. This is strong, stable and of superlative surface quality.

There is also an improvement to the Achromatic plug’s contact geometry, aiding the contact properties of the plug and the self-cleaning wiping action to ensure contacts are in optimal condition and to maximise signal transmission.

The third change Atlas made was around the rifling of the RCA pin. This improvement self-aligns the conductors during the cold weld processing, ensuring a superior stable connection.

Finally, there is a reduction in the overall mass of the RCA plug by 8% which has shown to improve signal transmission.

The above changes mean a solder-free, low mass, self-cleaning, recyclable RCA plug with a non-conductive body.



Ohno Continuous Casting Copper (OCC Copper)

The Ohno continuous casting method re-heats the extrusion as the molten copper is forced out of the mould and very slowly and gradually draws the grain or crystal down the conductor''s length, creating a ‘single crystal structure.’ Actually, because no copper is 100% pure, there will always be a few boundaries produced by impurities. The frequency of boundaries created are quite insignificant. A typical crystal in a copper conductor drawn to 0.3 mm diam. using the OCC process is 125.00 metres long!

The benefits are obvious, with almost no crystal boundaries, the audio signal is no longer impeded down the copper wire and more information and detail is delivered faithfully to the receiving equipment.

Atlas OCC Copper Design Process

Copper Purity Comparison (0.3mm Diameter)
  TPC OFC OCC
Purity >99.9% >99.99% >99.999%
Specific Gravity 8.75 8.926 8.938
Gas Impurities (ppm)
O2 200~500 <10 <5
H2 <0.5 <0.5 <0.3
Average Crystal Size (Metre) 0.007 0.02 125.00
Crystals Per Metre 150 50 0.008



PEF Dielectric

PVC (Poly Vinyl Chloride) is cheap to produce and, as such, is the most commonly used insulation in AV cables. However, PVC is the worst quality insulation a Hi-Fi or AV signal can encounter as its high loss causes a significant reduction in signal velocity. PVC is better suited to power cables and should be avoided in Hi-Fi and AV signal cables. Other dielectrics in common use are Polyethylene, Polypropylene and Polytetrafluoride Epoxy (better known as PTFE (Teflon™) or Teflon,) and the new and unique Atlas (PTFE). PEF (Foamed Polyethylene). The foaming process uses a blowing agent, of which there are two types. Atlas use the gas-foamed method which creates a more inert, consistent and higher quality product. The table below shows the properties of a selection of dielectrics. Though not used as a dielectric in Atlas' cables, PVC is included for comparison purposes.

Dielectric Material Comparison (0.3mm Diameter)
Property Polyvinyl Chloride (PVC) Foamed Polyethylene (PEF) Polypropylene (P.P) Teflon (FEP or PTFE) PTFE
Dielectric Constant (@ 50 -106Hz) 4-8 2.3 2.25 2.1 1.3
Dielectric Strength (kV mm-1) 23-30 30-50 30-50 20-25 N/A
Loss Tangent (% @ 50 - 106Hz) 8-15 0.02-0.05 0.02-0.06 (@ 106Hz) 0.02-0.07 N/A
Volume Resistivity (Ohms.cm @ 20°C) 1012-15 >1017 6.5x1014 >1016 N/A
Tensile Strength (Kg mm-2) 1.0-2.5 1.0-2.0 3.0-4.0 1.9-2.2 1.0
Melting Point (°C) -130 112-120 155-160 275 275
Max. Continuous Operating Temp. (°C) 60 75 90 200 260
Min. Operating Temp. (°C) -15 to -40 <-60 -5 to -45 <-60 -250



Co-ax Construction

Central conductor (signal path) surrounded by dielectric material encased within a circular conducting screen which acts as the signal return path.





Specification :

  • Construction : Co-ax
  • Material : 6n OCC Copper
  • Dielectric : PEF (foamed Polyethylene
  • Screen : dual drain 128 strands OFC
  • Capacitance : 54.35 pF/m
  • Inductance : 0.230 µH/m
  • Resistance : 0.065 Ohms/m I
  • Outside Diameter : 8.5mm



About Atlas Cables Made in United Kingdom

Atlas Cables are a major producer of interconnects and cables in the United Kingdom of Great Britain. All products are researched, developed and most are assembled in the Atlas purpose built factory in Scotland.

Many of these products are unique and use advanced techniques of production or manufacture in order to bring to the user the very finest quality products. With each new model we continue to push the boundaries of reliability and performance. It's little wonder then, that Atlas Cables have had so many mile-stone advances in the past and that Atlas Cables have secured so many awards in comparative tests against other products.

Specification :

  • Construction : Co-ax
  • Material : 6n OCC Copper
  • Dielectric : PEF (foamed Polyethylene
  • Screen : dual drain 128 strands OFC
  • Capacitance : 54.35 pF/m
  • Inductance : 0.230 µH/m
  • Resistance : 0.065 Ohms/m I
  • Outside Diameter : 8.5mm
