CYP 4x4 HDBaseT Lite Matrix with PoE, plus 2 additional independent HDMI zone outputs

£2,616.72 £2,180.60
SKU
PU-442PL-KIT
Free UK Delivery
24 Months
New
24 hours
what's this?
SPEAKER CABLES:

A quantity of 2 means you will receive a pair of speaker cables e.g. for your front left and front right speakers. By entering a quantity of 1, you will get a cable for a single speaker e.g. centre speaker and this option also enables you to vary the length (and termination) of your cable for each speaker.

OTHER CABLES:

A quantity of 1 means you will receive a single cable in the case of aerial, satellite, subwoofer, digital coaxial & optical cables and a pair of cables in the case of 2 rca to 2 rca analogue audio cables.

NON-CABLE PRODUCTS:

A quantity of 1 means you will receive 1 of the specified products.

Available

Need help? Call us on 0800 772 3688 or 0208 905 1555

Prefer email? Contact us via sales@futureshop.co.uk

This 4x6 HDBaseT™ Lite Matrix utilises four HDMI inputs and four HDBaseT outputs over a single CAT5e/6/7 cable (up to 60m) for each output, plus two additional HDMI outputs. Product Code - PU-442PL-KIT.

CYP 4x4 HDBaseT Lite Matrix with PoE, plus 2 additional independent HDMI zone outputs



This 4x6 HDBaseT™ Lite Matrix utilises four HDMI inputs and four HDBaseT outputs over a single CAT5e/6/7 cable (up to 60m) for each output, plus two additional HDMI outputs.

All six outputs are independent allowing any source to be distributed to any output. The HDBaseT outputs feature Power over Ethernet (PoE) functionality and allow the user to power the supplied PU-515PL-RX receivers without the need for a separate mains power supply.

The PU-442PL-KIT supports the transmission of video (resolutions up to 1080p Full HD and 1920x1200@60Hz), PoE, 2-way IR, multi-channel digital audio, and control via IR, RS-232, or Web GUI/Telnet IP. Use the IP control feature to enable users to access and control the matrix remotely and also allow additional options for integration of third-party control systems.



Compatible Receivers with this unit: PU-514L-RX, PU-514L-WPRX & PU-HBTL-ZE.



Features:

  • Product Code - PU-442PL-KIT
  • Supports all v1.3 HDMI resolutions
  • Supports uncompressed video/audio up to 10.2Gbps
  • Common supported resolutions: HDTV: 480p, 576p, 720p, 1080i, 1080p, 1080p24; PC: VGA, SVGA, XGA, WXGA, SXGA, UXGA, WUXGA
  • HDMI, HDCP and DVI complaint
  • High Definition Audio supported: Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio plus LPCM (up to 192kHz)
  • Uncompressed data transfer over single CAT cable (60m - CAT5e/6/7)
  • Supports HDMI input up to 15m 1080p 8bit or 10m 1080p 12bit
  • Supports RS-232, 2-Way IR, Manual Selection Buttons, and HDMI CEC control pass through
  • Selectable EDID settings - TV (downstream) and STD (fixed)
  • Compact 1U Rack mount design
  • Supports 3D signals
  • Supports additional IR Control via a master (ALL) Input/Output
  • Supports full IP control
  • Supplied with 4x PU-515PL-RX receivers
  • 2 Years Warranty



Specifications:

  • Inputs: 4x HDMI [4x HDMI Uncompressed AV and Data], 5x 3.5mm Stereo mini-jack [5x Infra Red Receiver], 1x 9pin Dsub [1x RS-232 Data], 1x RJ45 [1x IP Control], 1x USB Mini B [1x Service Port - Propriety Data]
  • Outputs: 4x RJ45 [4x HDBaseT Lite HDMI & Propriety Data], 2x HDMI [2x HDMI Uncompressed AV and Data], 5x 3.5mm Stereo mini-jack [5x Infra Red Emitter]
  • POE PSU: 24V/6.25A
  • Dimensions (WxDxH): 310mm x 250mm x 210mm
  • Gross Weight: 432g



8bit 10bit 12bit HDBT 3d POC



Box Contains:

  • CYP 4x4 HDBaseT Lite Matrix with PoE, plus 2 additional independent HDMI zone outputs (total 4x6 Matrix)
  • UK Power Supply
  • User's Manual
