Furutech Flow-8.1 NCF In-Line Power Filter
The Furutech Flow-8.1 NCF is an in-line AC filter for components that take a figure 8 (IEC C7) mains lead. It sits between your existing power cable and the component, so nothing in the system has to be replaced: the power cable plugs into the filter housing, and a short 60cm lead from the housing ends in a figure 8 plug that goes into the component. Furutech have built filters of this type for more than a decade, and the reasoning is that a system can only sound as clean as the electricity reaching it. Digital sources and switch-mode supplies both create and pick up high-frequency noise, and an in-line filter stops that noise getting into the component while also stopping noise generated inside it from spreading back into the mains and the rest of the system.
Filtering is handled by Furutech's AC-1501(R) EMI-filtering IEC inlet, a parallel network of an in-line coil and capacitors (2 x 0.3mH, Cx 0.1µF, Cy 3300pF) built into the inlet itself, with rhodium-plated Alpha non-magnetic copper alloy conductors and upgraded coils and capacitors. Furutech quote around 8dB of noise reduction at 100kHz, 14dB at 500kHz, 10dB at 1MHz and more than 30dB at 10MHz, the range where switching noise from digital equipment does most harm.
Vibration control matters as much as filtering here. The housing uses Furutech's Neo Damper Technology, the body is enhanced with NCF, and the cable clamp is formed with stainless steel and vibration-resistant metal powders to improve grip and reduce mechanically and electrically induced distortion. The figure 8 plug is Furutech's FI-8.1N NCF(R), with rhodium-plated pure copper contacts and an insulation body containing Nano Crystal² Formula, which eliminates static and damps vibration. The 60cm lead uses 37-strand silver-plated Alpha µ-OFC conductors (14AWG), an Alpha conductor shield, a flexible RoHS-compliant PVC sheath and a black vibration-damping nylon braid, around 11.5mm across.
The Flow-8.1 NCF is rated at 10A on 250V mains, which suits the low-current components that most often use a figure 8 inlet: CD and SACD players, streamers, DACs, music servers, network devices, compact amplifiers, headphone amplifiers, TVs and set-top boxes.
What Furutech say about the Flow-8.1 NCF
The Flow-8.1 NCF is a compact inline AC power filter for components fitted with a C7 IEC (figure-8) power inlet, installed between the power cable and the component. Its AC-1501(R) filtering circuit uses precision coils and capacitors to suppress incoming high-frequency EMI and RFI, while also limiting internally generated digital noise returning to the AC line. An NCF-enhanced body, Neo Damper technology and carefully engineered construction reduce vibration alongside electrical noise. It suits low-current source components such as CD players, streamers, DACs and music servers, with Furutech citing a quieter background, improved focus and greater low-level detail.
Inline Power Filter with NCF Technology for C7 IEC Components
Modern audio systems are increasingly populated by digital source components and switch-mode power supplies that both generate and receive high-frequency electrical noise. While often overlooked, these devices can introduce interference that degrades the performance of the entire system.
The Flow-8.1 NCF is Furutech's compact inline AC power filter, specifically designed for components equipped with a C7 IEC ("figure-8") power inlet. Installed between the AC power cable and the component, it creates an effective barrier against high-frequency EMI and RFI while simultaneously suppressing vibration transmitted through the power connection. The result is cleaner power delivery, lower system noise, improved transparency and greater musical realism.
Building on more than a decade of Furutech research into power filtering, the Flow-8.1 NCF combines our latest EMI filtering technology with the proprietary Nano Crystal² Formula (NCF) damping material first introduced in our flagship products. Inside, the proven AC-1501(R) filtering circuit employs precision coils and capacitors to suppress high-frequency interference while minimizing the transmission of internally generated digital noise back into the AC line, helping to preserve the performance of the entire audio system.
The Flow-8.1 NCF also incorporates Furutech's advanced mechanical resonance control, utilizing an NCF-enhanced body, Neo Damper technology and carefully engineered construction to reduce vibration-induced distortion alongside electrical noise. The result is a noticeably quieter background, improved focus, enhanced low-level detail, greater dynamic expression and a more natural, effortless musical presentation.
Whether used individually or throughout an entire system, the Flow-8.1 NCF represents one of the simplest and most effective upgrades for components fitted with figure 8 inlet.
Ideal Applications
The Flow-8.1 NCF is especially effective on low-current source components where digital noise can influence the performance of the entire system, including:
- CD and SACD players
- Streamers and network audio transports
- DACs with C7 power input
- Music servers
- Wireless network devices used in audio systems
- Small external power supplies
- TV and media players used in high-performance AV systems
- Compact integrated amplifiers using C7 power connections
- Headphone amplifiers with C7 IEC inlets
- Set-top boxes and digital video sources
Because the Flow-8.1 NCF also helps prevent internally generated switching noise from returning to the AC supply, it is particularly beneficial on digital source equipment operating alongside sensitive analogue components.
Key Features
- Specifically designed for components fitted with a C7 IEC ("Figure-8") power inlet
- Furutech NCF (Nano Crystal² Formula) body combining nano-sized ceramic particles, powdered carbon, nylon and fiberglass for simultaneous electrical and mechanical damping
- High-performance AC-1501(R) EMI filtering circuit
- Precision parallel filter network utilizing upgraded coils and capacitors
- Reduces conducted noise by approximately 10 dB at 1 MHz and over 30 dB at 10 MHz
- Rhodium-plated α (Alpha) non-magnetic copper alloy conductors
- FI-8.1N NCF(R) IEC connector
- α (Alpha) conductor shielding reduces radiated electrical noise
- Neo Damper vibration control throughout the filter assembly
- Flexible RoHS-compliant PVC outer sheath for additional vibration isolation
- High-grade polyethylene insulation for reduced capacitance and improved signal integrity
- Furutech's patent-pending metal cable clamp minimizes mechanical and electrical distortion
- Suppresses both incoming AC noise and internally generated digital noise
Specifications
General
- Brand: Furutech
- Model: Flow-8.1 NCF
- Type: In-line AC power filter, adapter type
- Rating: AC 125V 15A / AC 250V 10A, 50/60Hz
- Application: Between a power cable and a component with a figure 8 (IEC C8) inlet
- Cable Length: Approx. 60cm
- JAN: 4580370445510
Filtering Performance
- Filter: AC-1501(R) EMI-filtering IEC input, parallel circuit with in-line coil and capacitors
- Components: L 2 x 0.3mH, Cx 0.1µF, Cy 3300pF
- Noise Reduction: Approx. 8dB at 100kHz, 14dB at 500kHz, 10dB at 1MHz, more than 30dB at 10MHz
- Filter Conductors: Rhodium-plated α (Alpha) non-magnetic copper alloy
- Filter Construction: Ni-plated steel outer cover, PBT inner box and cover
- Damping: Neo Damper Technology, NCF-enhanced body
- Cable Clamp: Formed with stainless steel powder and vibration-resistant metal powder, patent-pending
- Certification: AC-1501(R) UL E134751, CSA 1224486
Connector
- Plug: Furutech FI-8.1N NCF(R) figure 8 (IEC C7)
- Contacts: α (Alpha) pure copper, rhodium plated
- Body: NCF (Nano Crystal² Formula) with nano crystalline, piezo ceramic and carbon powder
- Certification: PSE JET7872-43006-1001
Cable Construction
- Conductors: 37-strand silver-plated α (Alpha) µ-OFC, 0.26mm x 2 cores (14AWG, 1.96 sq mm)
- Insulation: High-grade flexible PVC (red, white), approx. 3.9mm diameter
- Filler: Polyester yarn
- Barrier Layer: Paper tape wrap
- Sheath: RoHS-compliant flexible PVC, approx. 10.0mm diameter
- Jacket: Vibration-damping nylon yarn braid (black)
- Outside Diameter: Approx. 11.5mm
- Treatment: All metal parts given the Furutech α (Alpha) Process (cryogenic and demagnetising)
About Furutech
Japanese maker of plugs, connectors and cables, with its own treated copper conductors and shielding materials.
Furutech is a Japanese company based in Tokyo. Its catalogue covers power connectors in IEC, UK, Schuko and other formats, signal connectors such as RCA and XLR, finished power, speaker, line, digital, USB and HDMI cables, and power distributors. It also makes bulk cable and accessories for phono and disc treatment.
Read more about Furutech Show less
A cryogenic and demagnetising treatment
The Alpha Process combines cryogenic treatment with demagnetisation, and Furutech applies it to its alpha-treated pure copper. It sits alongside Ohno Continuous Cast single-crystal copper in the conductor line-up, so the Furutech catalogue includes more than one route to a pure copper conductor.
Copper, silver and hybrid conductors
Furutech's materials include silver-plated copper and copper-silver hybrids as well as OCC and alpha-treated copper. DUCC and PC-Triple C copper appear in some of its cables. This range of conductors means the same plug design can be paired with different cable types.
NCF material and interference absorption
Furutech describes its NCF, short for Nano Crystal Formula, as generating negative ions and converting thermal energy into far infrared energy. It also uses a material called GC-303 to absorb electromagnetic interference. These are Furutech's own descriptions of what the materials are designed to do.
Why we stock Furutech
We do not just sell Furutech, we build with them. Their plugs and connectors go onto the custom cables we make in our own workshop, including cables for other brands in our range. When you fit a component by hand several times a week, you find out quickly whether it is well made.
Specifications
General
- Brand: Furutech
- Model: Flow-8.1 NCF
- Type: In-line AC power filter, adapter type
- Rating: AC 125V 15A / AC 250V 10A, 50/60Hz
- Application: Between a power cable and a component with a figure 8 (IEC C8) inlet
- Cable Length: Approx. 60cm
- JAN: 4580370445510
Filtering Performance
- Filter: AC-1501(R) EMI-filtering IEC input, parallel circuit with in-line coil and capacitors
- Components: L 2 x 0.3mH, Cx 0.1µF, Cy 3300pF
- Noise Reduction: Approx. 8dB at 100kHz, 14dB at 500kHz, 10dB at 1MHz, more than 30dB at 10MHz
- Filter Conductors: Rhodium-plated α (Alpha) non-magnetic copper alloy
- Filter Construction: Ni-plated steel outer cover, PBT inner box and cover
- Damping: Neo Damper Technology, NCF-enhanced body
- Cable Clamp: Formed with stainless steel powder and vibration-resistant metal powder, patent-pending
- Certification: AC-1501(R) UL E134751, CSA 1224486
Connector
- Plug: Furutech FI-8.1N NCF(R) figure 8 (IEC C7)
- Contacts: α (Alpha) pure copper, rhodium plated
- Body: NCF (Nano Crystal² Formula) with nano crystalline, piezo ceramic and carbon powder
- Certification: PSE JET7872-43006-1001
Cable Construction
- Conductors: 37-strand silver-plated α (Alpha) µ-OFC, 0.26mm x 2 cores (14AWG, 1.96 sq mm)
- Insulation: High-grade flexible PVC (red, white), approx. 3.9mm diameter
- Filler: Polyester yarn
- Barrier Layer: Paper tape wrap
- Sheath: RoHS-compliant flexible PVC, approx. 10.0mm diameter
- Jacket: Vibration-damping nylon yarn braid (black)
- Outside Diameter: Approx. 11.5mm
- Treatment: All metal parts given the Furutech α (Alpha) Process (cryogenic and demagnetising)
