Gefen GTB-UHD600-28S-RT 1x8 HDMI Splitter for 4K HDR
The Gefen GTB-UHD600-18S-RT takes one 4K Ultra HD source and sends it to eight displays at the same time, at the full 600MHz, 18Gbps bandwidth of HDMI 2.0. It handles up to 4K DCI-Cinema and 4K Ultra HD at 60Hz with 4:4:4 colour, as well as 1080p and 1920 x 1200 WUXGA. It passes HDR (HDR10 and HLG) with 10-bit Deep Colour, at 4K 60Hz 4:2:0 and 4K 24Hz 4:4:4. Audio passes through untouched, including LPCM 7.1 and the lossless high bit rate formats: Dolby Atmos, Dolby TrueHD, DTS:X and DTS-HD Master Audio.
What sets it apart from a basic splitter is that every output has its own scaler. An ordinary splitter in a mixed installation has to drop the whole system to whatever the weakest display can handle, so a single older 1080p screen pulls all eight down. Here, each output scales independently, automatically downscaling 4K to 1080p for a Full HD display while the 4K screens keep their full resolution. A built-in HDR-to-SDR conversion does the same job for displays that can't show HDR.
It's designed for large video distribution and digital signage. Gefen support more than ten layers of cascading, one splitter feeding others, so a single source can reach hundreds of displays. Smart CEC management talks to the source, other compatible splitters and the displays, making sure screens are switched on and set to the right input so there is always a picture. It also includes an IP-to-CEC bridge for control systems. A built-in 1080p test pattern generator, which also shows the unit's MAC address, makes installation and routine checks much quicker.
Control and setup are installer-friendly. It has IP control over Telnet and UDP from the Ethernet port, which can also cascade to compatible splitters, and a Mini-USB port that works as a virtual serial port for configuration and firmware updates. Advanced EDID management and audio mode selection let you integrate sources and displays quickly, and Gefen's Syner-G software finds the unit on the network automatically. It supports HDCP 2.2 and 1.4, 3D and lip-sync pass-through, and DVI sources and displays with adapters. Power comes from the supplied 5V locking supply, drawing 13W. The low-profile enclosure can be surface mounted.
What Gefen say about the GTB-UHD600-18S-RT
The Gefen GTB-UHD600-18S-RT is a powerful 1x8 HDMI splitter designed to route a full-bandwidth 4K Ultra HD 600 MHz source to up to eight 4K displays. Ideal for large-scale remote workstation access and digital signage applications, this splitter supports resolutions up to 4K DCI-Cinema (4096x2160 at 60 Hz) and HDR for stunning visual quality. With independent scalers for each output, it offers a flexible and scalable solution for professional AV and IT needs.
Key Features
High-Resolution Video: Supports resolutions up to 4K DCI-Cinema (4096x2160 at 60 Hz, 4:4:4 color space), 4K Ultra HD (3860x2160 at 60Hz, 4:4:4 color space), 1080p Full HD, and 1920x1200 (WUXGA), ensuring crystal-clear video quality.
HDR Support: Supports HDR (High Dynamic Range) 10-bit Deep Color at 4K 60 Hz 4:2:0 and 4K 24 Hz 4:4:4 for a wider range of colors and greater contrast.
Seamless Integration: Features IP control via Telnet and UDP, along with Smart CEC control, for easy integration into any professional AV system.
Audio Support: Supports LPCM 7.1, Dolby Atmos®, Dolby® TrueHD, DTS:X™, and DTS-HD Master Audio™ for immersive sound.
How It Works
The Gefen GTB-UHD600-18S-RT HDMI splitter operates by taking a single 4K source and distributing it to eight Ultra HD displays simultaneously. First, connect your source device, such as a Blu-ray player or computer, to the HDMI input. Then, connect up to eight displays to the HDMI outputs. The splitter automatically manages the signal, ensuring each display receives a high-quality image. With independent scalers for each output, it can even downscale the signal for 1080p displays, making it a versatile solution for any setup.
From the user manual:
The Gefen GTB-UHD600-18S-RT routes one full bandwidth 4K Ultra HD 600 MHz source to eight 4K Ultra HD 600 MHz or Full HD 1080p displays. Independent scalers built into each output will automatically downscale the signal when connected to a 1080p TV.
This HDCP-compliant product has been specifically designed to support over 10 layers of splitting/cascading for flawless performance in large video distribution and signage applications, supporting hundreds of displays.
Cutting edge Smart CEC Management system built into the GTB-UHD600-18S-RT communicates with the source, other compatible splitters and the displays. It guarantees that a picture is always present on all displays by ensuring that connected displays are on and switched to the correct input.
A built-in Pattern Generator helps in troubleshooting during installation or for routine maintenance. HDR and multi-channel digital audio including 7.1 channels of LPCM and HBR (High Bit Rate) lossless formats are also passed through. The Gefen 1:8 Splitter is the perfect choice for any small or large 4K video distribution system.
Features
- Simultaneously displays an Ultra Hi-Def source on up to eight Ultra HD displays
- Specifically designed to support multiple layers of splitting/cascading in large video distribution and signage applications, supporting hundreds of displays
- Supports 12-bit Deep Color at 1080p 4:4:4
- Supports HDR to SDR conversion
- Supports 4K to 1080P Auto-Downscale
- Supports built-in 1080P test pattern generator
- IP control via Telnet and UDP
- Supports Smart CEC control including IP to CEC bridge
- 3DTV pass-through
- Lip Sync pass-through
- EDID Management and Audio Mode selectors for rapid integration of source and displays
- Supports the use of DVI sources and DVI displays with HDMI-to-DVI adapters (not included)
- Gefen Syner-G™ software's Discovery and Show-Me features simplify initial IP configuration
- Advanced EDID Management via Virtual Serial over USB, Telnet or UDP
- In-field firmware update via USB or via web interface
- Low-profile, surface-mountable enclosure
Important: Cable quality is critical when handling 600 MHz HDMI signals. We highly recommend Gefen Locking HDMI cables. They have been designed and tested to work at 600 MHz and reliably transport the full 18 Gbps throughput of HDMI 2.0.
What's in the Box
(1) 4K Ultra HD 600 MHz 1:8 Splitter w/HDR and Scaling
(1) 5v/2.6A Power Supply (EXT-PS526AIP-LP-6)
(1) Quick-Start Guide
Specifications
General
- Brand: Gefen
- Model: GTB-UHD600-18S-RT
- Type: 1x8 HDMI splitter with HDR and scaling
- UPC: 888814007428
Video
- Maximum Resolutions: 4K DCI (4096 x 2160) and 4K Ultra HD (3840 x 2160) at 60Hz 4:4:4 8-bit, 1080p Full HD, 1920 x 1200 WUXGA
- Bandwidth: 600MHz TMDS / 18Gbps
- HDR: HDR10 and HLG, 10-bit Deep Colour at 4K 60Hz 4:2:0 and 4K 24Hz 4:4:4
- Deep Colour: 12-bit at 1080p 4:4:4
- Scaling: Independent scaler per output, automatic 4K to 1080p downscale
- HDR to SDR Conversion: Yes
- HDCP: 2.2 and 1.4
- Other: 3D and lip-sync pass-through, common VESA and CEA timings
- Test Pattern: Built-in 1080p 60Hz colour bar generator
Audio
- LPCM: Up to 8 channels, 192kHz, 24-bit
- Formats: Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, DTS, DTS-ES, DTS-HD High Resolution Audio, DTS-HD Master Audio, DTS:X
Distribution and Control
- Cascading: Over 10 layers, supporting hundreds of displays
- Smart CEC: Ensures displays are on and on the correct input; IP to CEC bridge
- IP Control: Telnet and UDP
- USB: Mini-USB virtual serial port for configuration, control and firmware updates
- EDID: Advanced EDID management via USB, Telnet or UDP
- Firmware: In-field update via USB or web interface
- Software: Gefen Syner-G Discovery and Show-Me
Connections
- Input: 1 x HDMI Type A 19-pin female
- Outputs: 8 x HDMI Type A 19-pin female
- Ethernet: 1 x RJ-45, for control or cascading
- USB: 1 x Mini-USB
- Power: 5V DC, locking, 5.5mm barrel / 2.1mm pin
Power and Environment
- Power Supply: 5V DC, 2.6A switching mode, locking (supplied)
- Power Consumption: 13W
- Operating Temperature: 0°C to +40°C ambient
- Storage Temperature: -20°C to +85°C
- Operating Humidity: 5% to 90% RH, non-condensing
- MTBF: 850,000 hours
Weight and Dimensions
- Dimensions: 263mm x 114mm x 25mm
- Net Weight: 1.2kg (2.5 lbs)
- Shipping Weight: 1.8kg (4.0 lbs)
- Mounting: Low-profile, surface-mountable enclosure
In the Box
- 1 x GTB-UHD600-18S-RT splitter
- 1 x 5V/2.6A locking power supply (EXT-PS526AIP-LP-6)
- 1 x Quick-Start Guide
