Matrix Audio MA-1 Audio Power Amplifier
The Matrix Audio MA-1 represents the brand’s move into traditional high-end amplification, forming the power foundation of the flagship M Series alongside the MS-1 music streamer and MP-1 preamplifier. Designed to handle both explosive dynamics and fine musical detail, the MA-1 delivers a confident, composed sound that suits a wide range of loudspeakers, from refined standmounts to power-hungry floorstanders.
At the heart of the MA-1 is a Class AB output stage using multiple high-power transistors per channel in a push-pull configuration, operating at a high bias current for strong linearity and control. In stereo or mono operation, it delivers 250W per channel into 8 ohms and 450W into 4 ohms, with the option to bridge two units for substantially higher output when required. Independent power supplies for left and right channels, a large transformer capacity, and extensive capacitor banks ensure stable current delivery and strong grip over the speaker load.
The MA-1 also offers flexible system integration. Balanced and unbalanced inputs are fully supported, with adjustable gain settings to match different preamplifiers and system sensitivities. Advanced thermal monitoring controls a near-silent cooling system that only activates when needed, keeping operation quiet in real-world listening. Finished in Matrix Audio’s new M Series industrial design, the MA-1 combines serious engineering with a bold visual presence, making it a compelling choice for listeners building a reference-level separates system.
Here is what Matrix Audio say about the MA-1
The all-new M series marks a milestone for Matrix Audio as it advances towards traditional Hi-Fi systems. This series includes the music streamer MS-1, the preamplifier MP-1 and the power amplifier MA-1, forming a complete flagship system of Matrix Audio that presents our understanding of Hi-Fi audio. The M series is the first lineup to adopt the new Matrix Design language, serving as a precursor to the future evolution of Matrix Audio products.
Evaluating audio products from the dimensions of "listening" and "looking" has always been our consistent philosophy. From concept to design, every step contains the love for music and the pursuit of beauty. MA-1 is Matrix Audio's first Class AB power amplifier. Its industrial design showcases our concept of simplicity. With hundreds of circular perforations of varying sizes and depths arranged in an array on the simple hexahedron, resembling rhythmic beats dancing and emerging on the surface.
The power amplifier serves as the backbone of the entire audio system, requiring comprehensive performance that excels both in dynamic and nuanced scenarios. It should surge powerfully during intense moments and delicately reveal subtleties with finesse. The MA-1 is born for the MS-1 and MP-1, offering precise matching and tuning to ensure that the entire system delivers exceptional audio performance and operational experience.
Multi-triode In Parallel Push-pull Output
In order to reduce the output impedance, we applied 10 ONSEMI high-power transistors in each channel to compose a push-pull amplification circuitry, which operating at a high bias current state. The static power consumption is up to 300W. At an 8-ohm load, it provides 250W output power per channel, and 450W output power per channel at a 4-ohm load.
United Efforts
The main amplifier of MP-1 consists of four independent fully balanced amplification units. Each channel has two amplification units working together, responsible for amplifying the in-phase and inverted signals. Even in RCA input mode, the signal will be converted into a bipolar signal for amplification, effectively suppressing common-mode noise and improving dynamic performance.
Stereo Mode
Each amplification unit in one amplifier handle left and right channels separately, every note is precisely reproduced on the stereo stage.
Bridged Mode
Joining two power amplifiers together, unleash more powerful energy for music, even speakers with demanding power requirements or low sensitivity will be driven effortlessly.
Mono Mode
Two amplifiers work for each channel, pursuing more extreme sound quality. It provides an even advanced driving mode for high-end separate speakers or bi-wiring speakers, unlocking the potential performance of the speakers.
Adjustable Gain
The amplifier has two gain levels. The normal gain is +30dB, which can be attenuated to +24dB. Allowing you to setup the amplifier with different pre-amps and speakers.
Surging Power
Independent transformers for the left and right channels enable a fully independent dual-channel design, with a total power supply of 1250VA. The main power is ±80V. Each channel features 14 parallel-connected 6,800µF capacitors, forming the main power supply filtering capacitor matrix. The total capacity of capacitors for both channels reaches 190,000µF. Compared to a single capacitor with the same capacity, multiple capacitors in parallel features lower equivalent internal resistance, ensuring greater flexibility in handling large current outputs.
Craftsmanship
The H-shaped structure is a unique design created by Matrix Audio for the M series products, born from two years of continuous optimization and improvement considering various aspects such as mechanics relationship, circuit layout, and exterior appearance. The 20mm CNC aluminum plate become the support structure of the entire device after dozens of procedures, serving as the core of the H-shaped structure. All components are mounted on the aluminum plate, and the entire weight is supported by heavy-duty feet installed on the main beam, making it solid and stable. After the panels are installed, multiple isolated cavities are formed with the main beam. Different circuit modules are properly placed in each cavity, effectively reducing interference between circuit modules. The circuit modules for the left and right channels are symmetrically arranged on both sides, creating a balanced visual impression.
Silent Cooling
The MCU continuously samples the temperature with two sensors on the main heatsink, constantly monitoring the temperature of the heatsink. When the temperature exceeds the preset value, a 7.4" ultra-quiet fan runs automatically and adjusts the fan speed dynamically. You'll hard to notice the fan is working even when the device is at low volume or muted. The isolated duct design ensures that there are no electronic components inside the airflow path, preventing dust accumulation from long-term operation.
Elegant & Refined
The ingenious industrial design is an indispensable part of our product, flowing out the brand-new Matrix Design language from dots, lines and surfaces. Each component undergoes multiple delicate CNC machining and surface treatments, providing a exquisite and comfortable matte texture, allowing you to feel the unique craftsmanship in operation, displaying a distinctive elegant temperament.
From Ears To Heartfelt
The MA-1 delivers a rich and exquisite sound, immersing you in its depths. It's not just an auditory pleasure but a heartfelt exchange. Every note, every chord tells a story, making you fall in love with the sound. Every detail of the M series embodies our pursuit of excellence. Everything you hear, see and touch is the final presentation by team Matrix Audio through continuous trial and fail, meticulous polishing, and careful calibration. We persevere tirelessly, striving to make things more beautiful and the sound more captivating.
Specifications
Audio Specifications
- XLR Input Impedance: 40kΩ
- RCA Input Impedance: 20kΩ
- Input Sensitivity: 1.48Vrms (Stereo/Mono), 1Vrms (Bridge)
- Output Power (Stereo/Mono mode)
- 2 × 250W RMS @ 8Ω
- 2 × 450W RMS @ 4Ω
- Output Power (Bridged mode)
- 1 × 500W RMS @ 8Ω
- 1 × 900W RMS @ 4Ω (Music signal only)
- Frequency Response: 20Hz–20kHz (+0, −0.15dB), 160kHz @ −3dB
- SNR
- 119dB @ +24dB A-weighting
- 123dB @ +30dB A-weighting
- THD+N
- <0.02% @ 250W / 8Ω (Stereo/Mono)
- <0.06% @ 500W / 8Ω (Bridged)
- Crosstalk: −125dB
- Gain: +24dB / +30dB
- Speaker Impedance
- Stereo/Mono mode: 2–16Ω
- Bridged mode: 4–16Ω
- Damping Factor: 350 @ 8Ω, 1kHz
Trigger
- Trigger In: DC 6–12V <10mA
- Trigger Out: DC 12V / 50mA (Max)
Power Specs
- Power Voltage: AC 100–120V or AC 220–240V, 50/60Hz (Factory fixed)
- Standby Power Consumption: <1W
- Idle Power Consumption: 250–350W
- Maximum Power Consumption: <1250W
Weight & Size
- Weight: 42.4kg (93.5 lb)
- Dimensions
- Width: 430mm (16.93")
- Depth: 518mm (20.39")
- Height: 201mm (7.91")
Accessories
- Power cable x1
- Trigger cable x1
- User manual x1
- Warranty card x1
About Matrix Audio
Matrix Audio UK is a renowned audio brand established in 2009 and based in the historic city of Xi'an, China. With a strong focus on developing, producing, and selling digital Hi-Fi audio products, Matrix Audio has evolved into a leading digital audio company over the course of over a decade.
Matrix Audio has built a stellar reputation among audiophiles in China and worldwide thanks to its commitment to delivering high-quality audio DACs, audio amplifiers, and other digital audio equipment. Their success can be attributed to the expertise of their professional testers, advanced research facilities, and state-of-the-art audio analysers.
The brand name "Matrix" is inspired by the mathematical concept of balance between two dimensions: portrait and landscape. Matrix Audio applies this concept to its product development and design philosophy. They prioritise excellent sound performance and strive for aesthetically pleasing designs that seamlessly integrate into any home environment. Harmony, both in sound and design, is the ultimate goal for Matrix Audio.
Choose Matrix Audio UK at Future Shop for cutting-edge digital Hi-Fi audio products that combine exceptional sound quality with captivating design, earning them a respected brand image and loyal following among audiophiles worldwide.
