Matrix Audio SC-1 Audio Grade Reference Clock
The Matrix Audio SC-1 is the brand’s first dedicated reference clock source, created to elevate the performance of digital audio components that support an external clock input. By providing a highly stable and accurate timing reference, the SC-1 helps compatible streamers, DACs, and disc players operate with greater precision, unlocking improvements in clarity, focus, and overall musical coherence.
At the heart of the SC-1 is a custom-designed OCXO module based on an SC-cut crystal. This advanced oscillator design offers exceptionally low phase noise and excellent long-term stability, supported by a tightly controlled oven environment that keeps the crystal operating at an optimal temperature. By reducing the effects of temperature variation, the SC-1 delivers a cleaner, more stable 10MHz reference signal with extremely low jitter, allowing connected devices to perform closer to their full potential.
The SC-1 provides four independently buffered BNC outputs, making it easy to clock multiple digital components from a single source. Housed in a solid, CNC-machined aluminium chassis and powered by a carefully engineered linear power supply, it is built for serious systems where timing accuracy matters. For listeners looking to extract the maximum performance from clock-compatible digital audio equipment, the SC-1 represents a meaningful step forward in system refinement.
Here is what Matrix Audio say about the SC-1
Matrix Audio proudly presents its first clock source product, meticulously designed for the streamers, DACs and CD players with synchronized reference clock inputs. With outstanding performance, it breathes new life into your audio system, unlocking a new realm of sound quality enhancement.
At the core of the SC-1 lies Matrix Audio's custom-made OCXO (Oven-Controlled Crystal Oscillator) module, utilizing an SC-cut crystal. Although this cutting process is highly complex, it enables the clock module with superior phase noise and aging characteristics. With precise temperature control by the oven chamber, the crystal operates in a highly stable environment, effectively minimizing the impact of ambient temperature fluctuations on phase noise and jitter.
Enjoy Local & Cloud Music
Mount your NAS drive to the device, allowing you to create a music library directly from your NAS. If your music is stored in the cloud, such as Baidu Netdisk, it can also be mounted directly on the device.
Dual USB 3.0
Two USB 3.0 Type A ports allow you to connect external storage or CD drives to the TT-1 for copying, ripping and playback.
SSD Storage - Fast And Quiet
The bottom of the device features an NVMe SSD slot, allowing for the installation of an SSD to expand internal storage. A specially designed ultra-low-noise independent power supply ensures a quiet operating environment for the SSD, which surpasses what an ordinary computer can offer..
Shareable Internal Storage
With the SMB protocol, computers on the same network can easily access the device's storage, making it simple to manage your music library. Additionally, the device can function as a NAS, enabling other streamers on the same network to seamlessly play the stored music.
Smart Wake Up & Trigger Control
Whether playing local music or online streaming audio, the device can be automatically woken up. And the back-end DAC or amplifier can be started through the trigger connection, which is automatic and convenient without any manual operation.
Excellent Clock System
This clock system derives from the flagship model of Matrix Audio, which has dual modes. In internal clock mode, the femtosecond clock provides a reference for the RF synthesizer, outputting a highly stable, low-phase-noise audio clock. In external clock mode, the incoming clock signals become the reference for the RF synthesizer, outputting an audio clock that is highly stable, low-phase-noise, and phase-synchronized with the input clock. When paired with Matrix Audio SC-1 audio-grade clock source, it can further tap into the audio performance potential of the device and move to an even higher level.
Multiple Interfaces
Optical, coaxial, AES/EBU and IIS-LVDS output ports are available, which can easily connect to various digital audio devices such as DACs and amplifiers to meet your diverse audio connection needs. If you connect it to an active speaker with digital input, you can also enable the digital volume function, no need to add an additional speaker controller, and the volume can be adjusted easily.
Ensure Pure Audio Transmission
NT-1 features an audio-specific USB DAC interface with electrical isolation. It not only deeply optimizes transmission noise, but also isolates the ground ware of USB port from the device ground wire, fundamentally reducing noise and interference during audio transmission and ensuring the purity of the audio signal.
It is worth mentioning that the linear power supply of NT-1 is unique, with independent windings and a precise low-noise regulator circuit, providing the USB DAC interface with a dedicated power supply isolated from the digital part, further ensuring the stability and low noise of audio transmission, and bringing you the ultimate Hi-Fi experience.
Flexible Connection Options
With different SFP modules, you can freely expand a optical fiber or Ethernet ports as needed. When used with audio grade network switch from Matrix Audio, it can create a more efficient and stable network connection to meet the needs of Hi-Fi scenarios.
Full Linear Power
The power supply system is built by a 60W toroidal transformer and multiple LDOs. The power for the digital audio processing core and the USB DAC interface are supplied by two independent windings of the transformer, ensuring stable operation of each part and effectively reducing noise interference.
Specifications
Clock Generator Specs
- 10.000 MHz ultra-low phase noise oven-controlled SC cut crystal oscillator
- Frequency accuracy (when shipped): <±0.01ppm
- Frequency stability vs temperature: <0.003ppm (−40°C to +70°C)
- Short-term stability: <5E-13 @ Tau = 1s
- Warm-up time: <5 minutes @ 25°C
Output Specs
- Output Ports: 4 × BNC independent driver buffers
- Output Waveform: Sine wave or square wave (factory fixed)
- Output Frequency: 10.000 MHz
- Output Level
- 0.5 Vrms (Sine wave)
- 1 Vrms (Square wave)
- Output Impedance: 50Ω
Phase Noise
- Measured at SC-1 output port
- 1 Hz: ≤ −118 dBc/Hz
- 10 Hz: ≤ −140 dBc/Hz
- 100 Hz: ≤ −150 dBc/Hz
- 1000 Hz: ≤ −160 dBc/Hz
- Noise Floor: ≤ −170 dBc/Hz
Jitter
- Measured at SC-1 output port
- 20 fs @ 1–100 Hz
Power
- Power Voltage: AC 100–120V 50/60Hz or AC 220–240V 50/60Hz (auto adaptive)
- Maximum Power Consumption: <20W
Weight & Size
- Weight: 4.4kg (9.7 lb)
- Dimensions
- Width: 330mm (12.99")
- Depth: 267mm (10.51")
- Height: 97mm (3.82")
Accessories
- Power cable x1
- Printed material x1
