MSolutions MS-210SP HDBaseT Extender Set - 4K to 40m (1080p to 70m)

£611.00 £509.17
SKU
MS-210SP
Free UK Delivery
12 Months
New
3 - 5 Days
what's this?
SPEAKER CABLES:

A quantity of 2 means you will receive a pair of speaker cables e.g. for your front left and front right speakers. By entering a quantity of 1, you will get a cable for a single speaker e.g. centre speaker and this option also enables you to vary the length (and termination) of your cable for each speaker.

OTHER CABLES:

A quantity of 1 means you will receive a single cable in the case of aerial, satellite, subwoofer, digital coaxial & optical cables and a pair of cables in the case of 2 rca to 2 rca analogue audio cables.

NON-CABLE PRODUCTS:

A quantity of 1 means you will receive 1 of the specified products.

Available

Need help? Call us on 0800 772 3688 or 0208 905 1555

Prefer email? Contact us via sales@futureshop.co.uk

The MSolutions MS-210SP is a 4K HDMI HDBaseT extender set allowing for uncompressed video and audio to be extended up to 40m at 4K UHD & HDR (10.2Gbps), and 70m at 1080p or lower resolutions. S/PDIF audio return enables the sink to return audio to an audio amplification or distribution device located remotely to the display.

MSolutions MS-210SP HDBaseT Extender Set - 4K to 40m (1080p to 70m)

The MSolutions MS-210SP is a 4K HDMI HDBaseT extender set allowing for uncompressed video and audio to be extended up to 40m at 4K UHD & HDR (10.2Gbps), and 70m at 1080p or lower resolutions. S/PDIF audio return enables the sink to return audio to an audio amplification or distribution device located remotely to the display. An additional one way analogue audio pass-through allows for a separate audio signal to be returned from the receiver to the transmitter. The unit also features RS-232 serial pass-through and single channel IR pass through from TX to RX, or RX to TX. HDBaseT compliant PoE allows for the RX unit to be powered remotely from the TX.

Features

  • Uncompressed extension of HDMI at resolutions up to 4K 60Hz 4:2:0 / 4K 30Hz 4:4:4 using HDBaseT technology
  • 4K signal extension to 40m over single CAT including HDR formats suppported under 10.2Gbps
  • 1080p or lower video resolutions up to 70m over single CAT
  • Supports HDMI pass-through all known HDMI audio formats including Dolby Atmos / DTS:X
  • HDBaseT 48V standard PoE support to power RX from the TX
  • Bi-directional S/PDIF (Digital Optical Toslink) connectivity (TX to RX, RX to TX)
  • Independent 1-way analogue audio pass-through (RX to TX)
  • Bi-directional RS-232 serial pass through
  • Single channel 5V IR pass-through (TX to RX, or, RX to TX)
  • CEC (Consumer Electronics Control) pass through
  • HDCP2.2 compliant

Specification

  • Video connectivity TX: 1x HDMI input (female), 1x HDBaseT output (RJ45 keystone)
  • Video connectivity RX: 1x HDBaseT input (RJ45 keystone), 1x HDMI output (female)
  • Digital audio connectivity (TX & RX): 2x S/PDIF Toslink Optical – send and receive
  • Analogue audio connectivity: 1x Analogue audio in (RX), 1x Analogue audio out (TX) – 3.5mm jack (female)
  • IR connectivity (TX & RX): 1x 3.5mm stereo jack (female) – IR TX or IR RX
  • RS-232 connectivity (TX & RX): 1x 5-pin phoenix connector, block included – serial pass-through and f/w upgrade
  • Power supply (TX): 1x 48V 0.5A DC
  • Power consumption: 15W
  • Individual unit dimensions (W x D x H): 135 x 70 x 31mm
  • Individual unit weight: 0.2kg
  • Operating temperature: 32°F to 104°F (0°C to 40°C)
  • Storage temperature: -4°F to 140°F (-20°C to 60°C)
  • Operating humidity: 0-80% non condensing

Package Contents

  • 1x MS-210SP transmitter
  • 1x MS-210SP receiver
  • 1x 48V 0.5A power supply with US, UK & EU territory clips
  • 1x IR receiver (5V) with 1m cable
  • 1x IR transmitter (5V) with 1m cable
  • 2 x Optical SPDIF (1.5m)
  • 1x User Guide

About MSolutions

The concept for the first MSolutions products for HDBaseT networks was conceived in 2016. Since then, they have developed state of the art multimedia and switching solutions for leading companies and integrators in the ProAV and across markets including public sector. The MSolutions team has been directly involved in HDBaseT development, support and sales since the standard was introduced in 2010. Their R&D team develops advanced, high quality systems that make media networks based on HDBaseT easier to install and more stable and enjoyable for end users.

MSolutions is committed to developing creative, reliable and value-oriented audio/video solutions and distributing them worldwide with an uncompromising level of service and support.

MSolutions takes great pride in the quality of its product range and offers a reliable service with timely technical support for customers in the field. When their customers purchase their products, they know they are getting a high quality, reliable and high performance product.

MSolutions consider the relationships with their customers to be crucial to their success. Every product carries a full guarantee and their commitment to providing a great service.

As MSoltuions continue to transform ideas into reality, they look forward to supporting you and your business needs today, tomorrow and beyond.

Specification

  • Video connectivity TX: 1x HDMI input (female), 1x HDBaseT output (RJ45 keystone)
  • Video connectivity RX: 1x HDBaseT input (RJ45 keystone), 1x HDMI output (female)
  • Digital audio connectivity (TX & RX): 2x S/PDIF Toslink Optical – send and receive
  • Analogue audio connectivity: 1x Analogue audio in (RX), 1x Analogue audio out (TX) – 3.5mm jack (female)
  • IR connectivity (TX & RX): 1x 3.5mm stereo jack (female) – IR TX or IR RX
  • RS-232 connectivity (TX & RX): 1x 5-pin phoenix connector, block included – serial pass-through and f/w upgrade
  • Power supply (TX): 1x 48V 0.5A DC
  • Power consumption: 15W
  • Individual unit dimensions (W x D x H): 135 x 70 x 31mm
  • Individual unit weight: 0.2kg
  • Operating temperature: 32°F to 104°F (0°C to 40°C)
  • Storage temperature: -4°F to 140°F (-20°C to 60°C)
  • Operating humidity: 0-80% non condensing

Package Contents

  • 1x MS-210SP transmitter
  • 1x MS-210SP receiver
  • 1x 48V 0.5A power supply with US, UK & EU territory clips
  • 1x IR receiver (5V) with 1m cable
  • 1x IR transmitter (5V) with 1m cable
  • 2 x Optical SPDIF (1.5m)
  • 1x User Guide
