NuPrime Evolution DAC - High-End DAC

£3,250.00 £2,708.33
SKU
NuPrime Evolution DAC
Free UK Delivery
24 Months
New
48 Hours
what's this?
SPEAKER CABLES:

A quantity of 2 means you will receive a pair of speaker cables e.g. for your front left and front right speakers. By entering a quantity of 1, you will get a cable for a single speaker e.g. centre speaker and this option also enables you to vary the length (and termination) of your cable for each speaker.

OTHER CABLES:

A quantity of 1 means you will receive a single cable in the case of aerial, satellite, subwoofer, digital coaxial & optical cables and a pair of cables in the case of 2 rca to 2 rca analogue audio cables.

NON-CABLE PRODUCTS:

A quantity of 1 means you will receive 1 of the specified products.

Available

Need help? Call us on 0800 772 3688 or 0208 905 1555

Prefer email? Contact us via sales@futureshop.co.uk

The Evolution DAC is NuPrime's top-of-the-line DAC, utilising premium components, seven digital filters and a bespoke power circuit. While it is capable of converting sample rate up or down, this feature is turned off when the input is an MQA stream to allow you to enjoy the full benefit of your high-res streaming.

NuPrime Evolution DAC - High-End DAC



The Evolution DAC is NuPrime's top-of-the-line DAC, utilising premium components, seven digital filters and a bespoke power circuit. While it is capable of converting sample rate up or down, this feature is turned off when the input is an MQA stream to allow you to enjoy the full benefit of your high-res streaming.



What NuPrime say

Most companies designed their high-end DAC by following the reference circuit from DAC chip company (such as ESS Technology). NuPrime takes it a step further with innovations surrounding the commodity chip.

To meet the highest performance requirement of the NuPrime Evolution Series, the power circuit of Evolution DAC has been redesigned from the ground up using C-Core transformers and AC filter, in addition to the DAC circuit. It utilizes one of the world’s highest performing 32-bit audio DACs, the ES9038PRO, and NuPrime PSRC IC chip to not only decode but also provide sampling rate up/down conversion from PCM 44.1kHz to PCM 768kHz and DSD64 to DSD512.



Features

  • NuPrime PSRC IC chip provides sample rate up/down conversion processing, from PCM 44.1kHz to PCM 768kHz and DSD64 to DSD512 (including PCM to/from DSD).
  • A proprietary NuPrime implementation capable of decoding DoP formats via coaxial and optical inputs (to support NuPrime source and server devices that are able to output DoP stream in addition to S/PDIF).
  • Seven digital filters.
  • Output Level variable or fixed mode.
  • Analog output phase change.
  • Analog output channel setting (both outputs can be set to Right, Left, R + L or L + R).
  • Display brightness adjustment.
  • Seven digital inputs for complete system flexibility. Full microprocessor control with memory retention for all inputs.
  • Custom designed non-linear volume curve.
  • USB Asynchronous transfer mode.
  • USB Supports DSD native playback by ASIO and DoP method. DSD is decoded natively with the same sample rate as the input source.
  • USB Supports native MQA decode.
  • Individually adjustable volume on each input for precise level matching of sources.
  • Exclusive driver software for Windows, standard driver software for Mac.
  • NuPrime vibration-free isolation feet.
  • Available in black or silver anodized aluminum finish.



Ultra Clean Power Circuit

AC Filter To get the cleanest and most stable power to the circuitry, no expense was spared when designing the power supply section of the Evolution DAC. The AC inlet goes right to a filter, which reduces the AC high frequency line noise by at least 20dB in the 100kHz to 5MHz region.
C-Core Transformer and Large Capacitor Bank

The filtered AC power is then fed to the AC power supply that utilizes C-Core transformers which has less stray flux than conventional ring type transformers. The stainless steel enclosures for the power supply provides shielding to minimize the transformer noise interference affecting other sensitive circuitry.

A large capacitor bank (around 70,000uF) using specialized capacitors, supplies ample and stable power to the analog and digital circuitry.

Discrete Transistors Taking things further, the analog section benefits from a NuPrime proprietary power circuitry crafted from discrete components. This circuitry provides further power stabilization and exhibits a high PSRR. Hence, the analog section is fed with the cleanest and most stable power we’ve put into any product. This translates to a superlative gain in audio performance that defines the Evolution series.
ES9038PRO DAC Chip The world’s highest performance 32-bit Stereo DAC (ES9038PRO). State-of-the-art DAC with warmer sonic characteristics.



MQA and Sample Rate Converter (SRC)

The Sampling Rate Converter is not active when the input is MQA, which is how it should work. You can experiment by using software unfolding and decoding on the PC Tidal application so that the Evo DAC receives a PCM stream rather than a MQA stream. With a PCM stream, you will then be able to use the SRC and perform upsampling. You can then compare the sound between the MQA stream and the upsampled PCM stream.



"..listening to Barenboim playing Mozart's Piano Concertos on CD was not very far from my idea of audio paradise. This DAC has a warmth and roundness to its musical presentation yet doesn't sacrifice any detail. There are some beautiful orchestral colours – for example, the piano was particularly well reproduced. It sounded fast and percussive, but at the same time subtle and lyrical too."

"This DAC took me to the heart of the performance, thanks to its ability to convey the intricacies of the subtle phrasing."

Steroenet - Product Review - August 2022



Specification

  • USB: Type B 2.0 Hi-Speed, data stream up to 384KHz/24Bit and DSD 256
  • IIS/DSD*: Supports PCM 768KHz/32Bit and DSD 512 data streams
  • COAXIAL: Supports PCM 44.1KHz ~ 768KHz/32Bit and DSD DOP 64,128 and 256
  • OPTICAL: Supports PCM 44.1KHz ~ 192KHz/32Bit and DSD DOP 64
  • AES/EBU: Supports PCM 44.1KHz ~ 192KHz/32Bit and DSD DOP 64
  • Analog Outputs Connectors:
  • 2 XLR balanced outputs: Fix mode 8Vrms or 4Vrms (user selectable). If set to variable output, the maximum output is 8Vrms.
  • 2 RCA unbalanced outputs: Fix mode 4Vrms or 2Vrms (user selectable). If set to variable output, the maximum output is 4Vrms.
  • Output Impedance: < 50 Ohm
  • Frequency response: 20 Hz – 20 KHz / ±0.3 dB. SNR: > 110 dB
  • THD+N: < 0.0003%
  • 0 dB=2 Vrms with Volume=87; +6 dB=4 Vrms with Volume=99
  • USB Audio Firmware: upgradable via USB DFU tool
  • Power Supply: AC voltage selector switch at the bottom of the unit, 115V or 230V
  • Aluminum remote control
  • Dimensions [W x H x D]: 430 mm x 55 mm x 315 mm
  • Weight: 5.2Kg
  • Power consumption: 13.5W (0.9W Standby)

*Note that the I2S output is for connecting to other NuPrime products and may not work with other devices.



About NuPrime

Nu-Prime Audio was founded in 2014 by Jason Lim, cofounder of NuForce, who is committed to design, engineering, and excellence. With a team of talented engineers, Nu-Prime has quickly established itself as a top player in the industry. Their high-end amplifiers and preamps, DACs and headphone amps, streamers, ethernet switches, and power supplies are pushing the boundaries of audio technology.

At Nu-Prime, the journey to audio perfection begins with a vertically integrated manufacturing process. Every step from conception to mass production is executed to ensure the best quality products. This dedication has been recognised by numerous audiophile magazines, solidifying Nu-Prime's reputation as a leader in the field.

Nu-Prime firmly believes that high-end audio should be accessible to all and prides itself on making expensive audio components affordable. Their design team optimises circuitry and components without compromising on the NuPrime sound signature. Each Nu-Prime product delivers a vast soundstage, lightning-fast dynamics, ultra-low distortion, and noise, allowing the music to emerge from a pristine background with intricate details and nuances intact.

Choose Nu-Prime Audio at Future Shop for the ultimate audio experience. Embrace their classic and elegant designs, immerse yourself in their signature soundstage, and witness the wide, lightning-fast dynamics that bring your music to life. With Nu-Prime, you can expect nothing less than a pristine audio experience where every delicate detail and nuance is preserved.





Digital

  • USB: Type B 2.0 Hi-Speed, data stream up to 384KHz/24Bit and DSD 256
  • IIS/DSD: Supports PCM 768KHz/32Bit and DSD 512 data streams
  • COAXIAL: Supports PCM 44.1KHz ~ 768KHz/32Bit and DSD DOP 64,128 and 256
  • OPTICAL: Supports PCM 44.1KHz ~ 192KHz/32Bit and DSD DOP 64
  • AES/EBU: Supports PCM 44.1KHz ~ 192KHz/32Bit and DSD DOP 64

Analog

  • Analog Outputs Connectors:
  • 2 XLR balanced outputs: Fix mode 8Vrms or 4Vrms (user selectable). If set to variable output, the maximum output is 8Vrms.
  • 2 RCA unbalanced outputs: Fix mode 4Vrms or 2Vrms (user selectable). If set to variable output, the maximum output is 4Vrms.
  • Output Impedance: < 50 Ohm
  • Frequency response: 20 Hz – 20 KHz / ±0.3 dB. SNR: > 110 dB
  • THD+N: < 0.0003%
  • 0 dB=2 Vrms with Volume=87; +6 dB=4 Vrms with Volume=99

General

  • USB Audio Firmware: upgradable via USB DFU tool
  • Power Supply: AC voltage selector switch at the bottom of the unit, 115V or 230V
  • Aluminum remote control
  • Dimensions [W x H x D]: 430 mm x 55 mm x 315 mm
  • Weight: 5.2Kg
  • Power consumption: 13.5W (0.9W Standby)

Note that the I2S output is for connecting to other NuPrime products and may not work with other devices.
