SEADA SD-MB-01 4K Magic Box
The SD-MB-01 Magic Box is a versatile audio and video processor designed for high-performance AV testing and calibration. Serving as a signal generator, it delivers up to 30 unique test pattern signals, making it an essential tool for video troubleshooting and diagnostics. Featuring a built-in scaler, the SD-MB-01 supports both upscaling and downscaling to custom resolutions within the 4K range. It offers full control over output formats and can rotate video at 0°, 90°, 180°, or 270°, ensuring seamless display alignment in any setup. Ideal for AV professionals, this processor allows custom EDID configurations through DIP switches or RS232 commands, providing extensive flexibility for integration with different displays. The SD-MB-01 also supports audio embedding at HDMI input and audio de-embedding at HDMI output, making it an efficient component in complex AV workflows.
Here is what SEADA say about the SD-MB-01 4K
SD-MB-01 Magic Box is a multifunctional, advanced audio and video processor.
Key Features
- Supports Signal Generation
- Supports output resolution customisation
- Supports input EDID management
- Supports up and downscale
- Supports signal cropping
- Supports customised output signal window size
- Supports customised output signal window position
- Supports signal rotation of 90/180/270
- Supports audio embedding
- Supports audio de-embedding
- Supports customised preset layouts
- Supports HDMI1.4、HDCP1.4、HDMI2.0、HDCP2.2
- Supports up to 4K@60Hz for both input and output
- Supports multiple control methods, including front panel buttons, IR remote and the RS232 control
- Supports USB upgrading
Specifications
Video
- INPUT PORT: 1x HDMI2.0
- INPUT RESOLUTION: Up to 3840×2160@60HZ
- OUTPUT PORT: 1xHDMI2.0
- OUTPUT RESOLUTION: Up to 3840×2160@60HZ
Audio
- INPUT PORT: 1x HDMI, 1*3.5mm Analog
- INPUT AUDIO SIGNAL: RAW PCM, 16 bit, 32/44.1/48KHz sps; PCM 2.0
- OUTPUT PORT: 1* HDMI2.0, 1* Analog Audio(3.5mm audio)
- OUTPUT AUDIO SIGNAL: RAW PCM, 16 bit, 32/44.1/48KHz sps; PCM 2.0
Control
- FRONT CONTROL: ROTATE
- IR: IR REMOTE CONTROLLER (NOT INCLUDED IN PACKAGE)
- RS232: 3-PIN PHOENIX
Others
- OPERATING TEMPERATURE: 0 to +45 C (32 to + 113 F)
- STORAGE TEMPERATURE: -20 to +70 C (-4 to + 158 F)
- HUMIDITY: 10% TO 90%
- POWER ADAPTER: DC 12 V 1.5A
- POWER CONSUMPTION: 10W(MAX)
- DIMENSIONS: 138x85x28
About SEADA
SEADA Technology Limited is a UK based, 2019 Queens Award for Enterprise winning, world-leading manufacturer of Video Wall Controllers, Conference technology and Pro AV solutions.
SEADA’s mission is to offer the most innovative and cost-effective solutions for our customers, in video wall controller applications. SEADA is proud to be located in Birmingham, England, the birthplace of British Engineering. All our products are manufactured and tested at our UK facility.
Specifications
Video
- INPUT PORT: 1x HDMI2.0
- INPUT RESOLUTION: Up to 3840×2160@60HZ
- OUTPUT PORT: 1xHDMI2.0
- OUTPUT RESOLUTION: Up to 3840×2160@60HZ
Audio
- INPUT PORT: 1x HDMI, 1*3.5mm Analog
- INPUT AUDIO SIGNAL: RAW PCM, 16 bit, 32/44.1/48KHz sps; PCM 2.0
- OUTPUT PORT: 1* HDMI2.0, 1* Analog Audio(3.5mm audio)
- OUTPUT AUDIO SIGNAL: RAW PCM, 16 bit, 32/44.1/48KHz sps; PCM 2.0
Control
- FRONT CONTROL: ROTATE
- IR: IR REMOTE CONTROLLER (NOT INCLUDED IN PACKAGE)
- RS232: 3-PIN PHOENIX
Others
- OPERATING TEMPERATURE: 0 to +45 C (32 to + 113 F)
- STORAGE TEMPERATURE: -20 to +70 C (-4 to + 158 F)
- HUMIDITY: 10% TO 90%
- POWER ADAPTER: DC 12 V 1.5A
- POWER CONSUMPTION: 10W(MAX)
- DIMENSIONS: 138x85x28
