SVS 3000 Micro R|Evolution
The SVS 3000 Micro R|Evolution exists to solve the compromise that defines almost every compact subwoofer: shrink the cabinet and you surrender output, extension and control. SVS attack that by putting two 9-inch high-excursion drivers into an 11-inch sealed enclosure, mounted opposing one another and firing from the sides, wired acoustically and electrically in parallel. Because the two drivers move in perfect opposition, their reaction forces cancel, so the cabinet stays inert even at full excursion instead of walking across the floor or rattling the shelf it sits on. Each driver carries 27.3mm of Xmax on an NBR extreme-excursion surround, a one-piece 1100 aluminium cone and a four-layer copper voice coil, which is what allows a box this size to move enough air to reach 20Hz.
Driving them is a discrete Class D amplifier rated at 1,200 watts continuous and over 4,000 watts peak, a 50% increase in RMS power over the previous generation. Four 60A 200V MOSFETs in full bridge configuration deliver more than 100Vrms across the pair, fed by a digitally controlled switch mode supply that holds a regulated 160V rail and monitors incoming AC conditions to adapt to the mains it finds. Behind it sits a 295MHz Analog Devices DSP with 56-bit double precision filtering and five times the processing power of earlier SVS designs, running real-time excursion and current monitoring thousands of times per second. Distortion is held below 0.05% THD+N at rated power.
Practical control is where it earns its place in a living room. The SVS Subwoofer Control app connects over Bluetooth from iOS, Android or Fire devices and exposes volume, a fully adjustable low pass filter, phase, polarity, six parametric EQ bands, room gain compensation and three memory presets, plus Auto Room EQ that measures the response at the listening seat using the phone's microphone. Connection is by unbalanced RCA or balanced XLR, with 12V trigger and IR inputs for control systems and a rear OLED display with a flip function for upside-down installations.
What SVS say about the 3000 Micro R|Evolution
Reference subwoofer performance is now available in micro form. 3000 Micro R|Evolution delivers effortless, authoritative output to 20Hz with breathtaking musical accuracy, all from a lifestyle-friendly 11-inch cabinet that fits nearly anywhere.
A New Reference Standard for Micro Subwoofers.
The challenge of designing a truly compact subwoofer is balancing size with performance. Traditional micro designs sacrifice output, control, and musical accuracy in pursuit of a room-friendly enclosure, depriving users of a true subwoofer experience. The 3000 Micro R|Evolution is a revelation.
Drawing from the flagship SVS subwoofer platform, 3000 Micro R|Evolution represents a complete reimagining of compact subwoofer design by delivering infrasonic extension to 20Hz, stunning dynamic output, and musicality fit for the most demanding audiophiles. All from a handsomely compact 11-inch enclosure.
Owing to the advancements in driver, amplifier, and DSP technology, the 3000 Micro R|Evolution energizes a room with authority while preserving the nuance, texture, and tonal accuracy demanded by serious music listeners and home theater fans. When combined with advanced tuning and control features from the SVS Subwoofer Control app, it's an unrivaled subwoofer experience.
Specifications
General
- Brand: SVS
- Model: 3000 Micro R|Evolution
- Product Type: Active sealed subwoofer
- Cabinet Type: Sealed
- Finishes: Piano Gloss Black, Piano Gloss White
- Standby Power Consumption: 0.5W
- Compliance: RoHS compliant, lead-free construction, worldwide safety certifications
- Warranty: 5-year unconditional warranty
Performance
- Frequency Response: 20Hz to 230Hz ±3dB
- Measurement Conditions: 2-metre ground plane away from reflective structures (quasi-anechoic)
- Amplifier Distortion: Less than 0.05% THD+N at rated power (70% to 90% lower than previous generation)
- Acoustic Distortion: 20% to 60% lower acoustic THD+N in the critical low frequency bandwidth compared to the previous generation
- Roll-off Slope: Optimised to take maximum advantage of available room gain
Drivers
- Configuration: Dual opposing side-firing 9-inch high-excursion active drivers, acoustically and mechanically in parallel
- Excursion: 27.3mm Xmax, 32.6mm Xmech, precision aligned
- Motor: Precisely tuned overhung configuration with oversized Y30 ferrite motor system
- Cone: 1100 aluminium single-piece cone and coupler
- Voice Coil: High-current 4-layer copper winding
- Former: High-temperature 3003-H18 aluminium former and bobbin
- Surround: Proprietary injection-moulded NBR, built for extreme excursion
- Spider: 5-inch composite linear spider
- Leads: Dual balanced 24-strand silver-plated Litz wire, high temperature
- Basket: Custom 9-inch FEA-optimised powder-coated steel frame
- Shorting Ring: 6063 aluminium
- T-Yoke and Top Plate: Oversized low carbon 08AL steel
Amplifier
- Rated Power: 1,200 watts continuous
- Peak Power: Over 4,000 watts
- Topology: Discrete Class D with fully discrete MOSFETs
- Output Devices: Four 60A 200V MOSFETs in full bridge configuration, over 100Vrms across both drivers
- Increase Over Previous Generation: 50% higher RMS power output
- Power Supply: Digitally controlled Switch Mode Power Supply with high-efficiency low EMI resonant LLC topology
- Rail Voltage: Consistent regulated 160V, with digital monitoring of AC input mains voltage and current
Digital Signal Processing
- Processor: 295MHz Analog Devices Audio DSP
- Filtering: Double precision 56-bit
- Processing Power: Over 5x that of previous SVS subwoofers
- Conversion: Premium DACs with more than 120dB signal-to-noise ratio
- Power Management: Real-time monitoring of power, driver excursion and current thousands of times per second
- Protection: Multi-point thermal, voltage and current monitoring
Connections
- Unbalanced Input: RCA, 10kΩ input impedance, compatible up to 4Vrms
- Balanced Input: XLR, 18kΩ input impedance, compatible up to 4Vrms / +14dBu
- Trigger Input: 3.5mm, 3-12V AC/DC
- IR Input: 3.5mm, for integration with control systems
- USB: Provides power for the SVS SoundPath Wireless Audio Adapter (sold separately)
- Mains: IEC inlet, 6-foot heavy-duty high-current power cord supplied
Control and App
- App: SVS Subwoofer Control, connecting over Bluetooth
- Platforms: Apple iOS, Google Android, Amazon Fire
- App Functions: Volume, fully adjustable low pass filter, phase, polarity, six parametric EQ bands, room gain compensation, power management settings
- Presets: Three memory presets for music, movies, night mode and more
- Auto Room EQ: Measures in-room performance using the mobile device microphone or an accessory microphone, then calculates precision equalisation filters for the listening position
- Feedback: Bidirectional, showing adjustments in real time on both app and subwoofer interface
- Onboard Interface: Rear panel OLED display and controls with a Display Flip function
- Power Modes: Auto/On and Trigger options selectable through the app
Cabinet
- Construction: Robust Medium Density Fibreboard (MDF) with internal bracing
- Baffles: Extra thick side-baffles supporting the drive units
- Damping: Highly reinforced internal design with acoustic insulation to eliminate coloration and resonance
- Grilles: Protective non-resonant perforated steel mesh
- Feet: Screw-in iso-elastomer feet to reduce noise artifacts and improve stability
Weight and Dimensions
- Dimensions (including grilles): 278mm (H) x 298.8mm (W) x 273.6mm (D)
- Dimensions in Inches: 10.9" (H) x 11.8" (W) x 10.8" (D)
- Net Weight: 10.2kg (22.5 lbs)
- Packaged Dimensions: 349mm (H) x 379mm (W) x 370mm (D)
- Packaged Weight: 12.8kg (28.3 lbs)
In the Box
- 1x 3000 Micro R|Evolution subwoofer
- Isolating elastomer feet
- Heavy-duty, high-current 6-foot power cord
- Quick Start Guide
About SVS
SVS is an American loudspeaker manufacturer founded in 1998 and best known for producing subwoofers and speakers that consistently outperform their price point. The company was founded on the principle that high-performance bass should be accessible rather than the exclusive preserve of high-end systems, and has built a reputation through direct owner feedback, rigorous measurement discipline, and a willingness to support its products with one of the most customer-friendly guarantees in the industry. SVS designs its subwoofers and speakers in-house, combining acoustic engineering with DSP development to produce products that measure well and, more importantly, sound right in real rooms. The SoundPath accessory line extends the same engineering approach to cables, isolation products, and wireless adapters, designed to complement SVS hardware without requiring brand loyalty to deliver results.
About SVS
American maker of subwoofers and loudspeakers, developed for low extension, high output and accuracy.
SVS is based in Youngstown, Ohio, and makes subwoofers and loudspeakers. Its subwoofer series include the 1000 Pro, 2000 Pro, 3000 and 5000 R|Evolution and the 17-Ultra R|Evolution. Speaker lines include Prime, Ultra Evolution and the Prime Wireless Pro, so you can build a stereo or home cinema system.
Read more about SVSShow less
Subwoofers are arranged in series
The range runs from the 1000 Pro and 2000 Pro to the 3000 and 5000 R|Evolution, with the 17-Ultra R|Evolution as the largest model. Check the specification for room size and output. Larger models generally suit larger rooms and more demanding listening, so match the model to your room.
Design aims are stated clearly
SVS names low extension, high output, accuracy, speed and integration as the aims of its engineering. It says its speakers and subwoofers are tested both in an anechoic chamber and in real rooms. You can use those aims as a guide when matching a subwoofer to your room.
Speakers extend the system
The Prime, Ultra Evolution and Prime Wireless Pro speaker families sit alongside the subwoofers, so you can build a stereo or home cinema system from one maker. Check the product page for the model you choose, and for how it connects to a subwoofer in your room.
