Astell&Kern A&ultima SP4000 Digital Audio Player
Building on the legacy of the SP3000, this next-generation player introduces an advanced Octa audio circuit architecture with a 1:1 digital-to-analog structure. Each AK4191 digital processor pairs directly with an AK4499EX DAC, delivering exceptional signal precision and improved separation. The SP4000 achieves a true Quad DAC configuration, producing an extraordinary 131dB Signal-to-Noise Ratio for pure, lifelike sound. With twice the OPAMPs in parallel compared to its predecessor, it delivers richer detail, deeper bass, and a more expansive soundstage.
High Driving Mode ensures stable power delivery for any headphone, while ESA (Enhanced Signal Alignment) technology reduces group delay, resulting in crystal-clear audio with minimal distortion. A newly integrated Low Dropout Regulator, inspired by high-precision medical and 5G devices, reduces noise by up to 97% for unmatched purity. The SP4000 is designed for those who demand ultimate sonic performance, transforming every track into an immersive listening experience.
Features
- Enhanced signal processing capabilities with Octa audio circuit architecture
- Supports High Driving Mode for delivering premium sound quality
- Minimizes group delay with proprietary ESA (Enhanced Signal Alignment) technology
- Ultra Low Noise LDO Regulator for top-tier noise suppression
- Precision sound achieved with Any Layer Type PCB
- Equipped with a 99.9% Pure Copper Shield Can
- First Astell&Kern Device to Support Full Android OS
- First Astell&Kern Device to Feature Advanced DAR Technology
- Features 4.5th generation UI, combining functionality and emotional design
Top-Tier Noise Suppression (Ultra Low Noise LDO Regulator)
The SP4000 features a newly implemented LDO (Low Dropout) Regulator in its power supply, which reduces noise by up to 97% compared to previous models. LDO Regulators are high-performance components typically used in precision medical devices and 5G communication equipment. They help stabilize battery voltage and effectively suppress noise, resulting in cleaner, purer sound.
Precision Sound with Any Layer HDI PCB
To achieve the highest sound quality, the SP4000 incorporates top-tier Any Layer HDI (High-Density Interconnect) PCB technology. Commonly used in smartphones and high-performance electronic devices, this advanced circuit board allows for the precise design of complex circuitry within a compact space. It minimizes signal loss, enabling the delivery of a more refined and detailed sound.
Supports High Driving Mode for Premium Sound Performance
The SP4000 features twice as many OPAMPs arranged in parallel compared to its predecessor, delivering richer and more detailed sound. High Driving Mode provides powerful and stable output—much like a four-wheel-drive vehicle confidently navigating rough terrain. It’s designed to reproduce even the most delicate sonic details with precision, allowing you to enjoy deeper, clearer, and more immersive music.
Specifications
- Model SP4000 (PPF51)
- Body Color Black, Silver
- Body Material Stainless Steel 904L
- Display 6inch 2K (2160 x 1080) touch screen
- Supported Audio Formats WAV, FLAC, WMA, MP3, OGG, APE, AAC, ALAC, AIFF, DFF, DSF
- Sample rate PCM : 8kHz ~ 768kHz (8/16/24/32bits per Sample)
- DSD Native : DSD64(1bit 2.8MHz), Stereo | DSD128(1bit 5.6MHz), Stereo
- DSD256(1bit 11.2MHz), Stereo | DSD512(1bit 22.4MHz), Stereo
- Output Level Unbalanced 4.1Vrms │ Balanced 8.2Vrms (Condition No Load)
- CPU Octa-core
- DAC AKM4191 x4 + AKM4499EX x4 (Real Quad DAC)
- Decoding Support up to 32bit / 768kHz Bit to Bit playback
- Input USB Type-C input (for charging & PC & MAC)
- Outputs Unbalanced Out (3.5mm), Optical Out(3.5mm)
- Balanced Out (4.4m, only 5-pole supported)
- Wi-Fi 802.11 a/b/g/n/ac (2.4/5GHz)
- Bluetooth V5.0 (A2DP, AVRCP, Qualcomm® aptX™ HD, LDAC, LHDC, SBC, AAC)
- Dimensions 3.34” (85mm)[W] x 5.89” (149.8mm)[H] x 0.76” (19.5mm)[D]
- Weight About 21.7oz (615g)
- Feature Enhancements Firmware upgrade supported (OTA)
- Operating Temperature 0℃ ~ + 40℃ (32℉~ 104℉)
About Astell&Kern
Astell&Kern is the ultimate digital music source that brings you Mastering Quality Sound or MQS. Astell means ‘Stars’ in Latin and Kern means ‘Center’ in German. We believe Astell&Kern is the center of music.
Today, original music performances can be captured in digital almost exactly as they were performed due to new, advanced recording technology currently available. However, these high quality recordings are mainly listened to through inferior sound formats, such as MP3 or through streaming services. With the debut of the MP3 format, music lovers sacrificed sound quality for the convenience of being able to carry their music collection wherever they went. Because the MP3 format heavily compresses files for the sake of convenience, the vocals and instruments you hear are only an inferior version of the original. The soundstage and the ambience of the original performance often disappears when listening to compressed MP3 music. After pondering these issues, Astell&Kern was our solution to poor sound quality for the sake of portability, and our way in reviving the original sound quality of music, MQS, for music artists, recording engineers, and professionals.
Astell&Kern's pursuit is to provide natural and original sound without distortion. It showcases the presence of the original recording with miniscule details you may not have noticed from other music systems, while playing back high-resolution music bit by bit, exactly as it was recorded. The ability to play back the exact recording of any live performance is what Astell&Kern is known for.
The power of true sound from Astell&Kern can now be experienced and has been part of many famous audio exhibitions around the world. Astell&Kern is now admired by music lovers from many countries, including the USA, China, Japan, UK, France, and many more around the world.
About Astell&Kern
Korean maker of portable digital audio players, with a catalogue that also covers earphones, headphones and speakers.
Astell&Kern is a Seoul-based company and part of Dreamus, formerly iRiver. Its core product is the digital audio player, a portable unit that holds your music library and drives headphones or earphones directly. The catalogue also includes earphones, headphones, speakers, cases and other accessories for your player.
Read more about Astell&Kern Show less
Players are grouped into named series
A&ultima is the flagship line, with the SP4000 and SP3000 among its models. A&futura includes the SE300 and A&norma includes the SR35. The PD series, which includes the PD20, and the KANN line, which includes the KANN ULTRA, are separate families. Each series sits at a different level of price and specification.
High-resolution files are supported across the range
Astell&Kern lists playback of 24-bit files at sample rates from 44.1kHz to 192kHz, and supports MQS, its Mastering Quality Sound label. If you want to play DSD or sample rates beyond that, check the specification of the model you are considering before you buy.
Earphones, speakers and cases sit alongside the players
Astell&Kern also makes earphones, headphones, speakers and accessories, including cases. It has worked with VOLK Audio on the STELLA in-ear monitors. If you are buying a player, the catalogue lets you choose the earphones and the case from the same maker.
Why we stock Astell&Kern
We had DACs but nothing portable, so we went looking. Astell&Kern do one thing and have done it longer than almost anyone, with a range that runs from a first serious player up to real money. If you have invested in in-ear monitors and are still feeding them from a phone, this is the gap they fill.
Specifications
- Model SP4000 (PPF51)
- Body Color Black, Silver
- Body Material Stainless Steel 904L
- Display 6inch 2K (2160 x 1080) touch screen
- Supported Audio Formats WAV, FLAC, WMA, MP3, OGG, APE, AAC, ALAC, AIFF, DFF, DSF
- Sample rate PCM : 8kHz ~ 768kHz (8/16/24/32bits per Sample)
- DSD Native : DSD64(1bit 2.8MHz), Stereo | DSD128(1bit 5.6MHz), Stereo
- DSD256(1bit 11.2MHz), Stereo | DSD512(1bit 22.4MHz), Stereo
- Output Level Unbalanced 4.1Vrms │ Balanced 8.2Vrms (Condition No Load)
- CPU Octa-core
- DAC AKM4191 x4 + AKM4499EX x4 (Real Quad DAC)
- Decoding Support up to 32bit / 768kHz Bit to Bit playback
- Input USB Type-C input (for charging & PC & MAC)
- Outputs Unbalanced Out (3.5mm), Optical Out(3.5mm)
- Balanced Out (4.4m, only 5-pole supported)
- Wi-Fi 802.11 a/b/g/n/ac (2.4/5GHz)
- Bluetooth V5.0 (A2DP, AVRCP, Qualcomm® aptX™ HD, LDAC, LHDC, SBC, AAC)
- Dimensions 3.34” (85mm)[W] x 5.89” (149.8mm)[H] x 0.76” (19.5mm)[D]
- Weight About 21.7oz (615g)
- Feature Enhancements Firmware upgrade supported (OTA)
- Operating Temperature 0℃ ~ + 40℃ (32℉~ 104℉)
