Furutech Pure Power 6 NCF Top-of-the-Line Power Distributor

Furutech Pure Power 6 NCF Top-of-the-Line Power Distributor

Furutech upgrade their Pure Power 6 AC Mains Distributor, the ultimate expression of Furutech’s Pure Transmission Technology. Furutech engineers each and every step of power and signal transfer--no matter how small--using the finest materials and technologies available, like their proprietary Formula GC-303 EMI-absorbent material and Two-Stage Cryogenic and Demagnetizing Super α (Alpha) Treatment applied to all metal parts.

The Pure Power 6 NCF is built like a Swiss bank vault, a virtual black hole for EMI and RFI. The substantial, beautifully-crafted chassis is precision CNC-machined from a solid aerospace-grade aluminium alloy that effectively shields against RFI (Radio Frequency Interference).

Three separate milled compartments house three independently-wired duplex receptacles using top-quality Fluorpolymer-shielded high-purity silver-plated Alpha-OFC. The hot and neutral conductors from the IEC loom into a large, centrally-located chamber--secured Bugatti-like with eight beautifully machined rivets--that’s filled with Furutech’s EMI-absorbent Formula GC-303 material. GC-303 absorbs the high-frequency noise that develops whenever passing current through wire.

Furutech’s patented GTX-D NCF Receptacles enhance the vault-like build, ensuring the tightest and most secure power cord fit imaginable. Pure Transmission Technology is applied at every level: The rhodium-plated receptacles are not simply flush with the outer chassis but tapped 25mm into the thick aluminium for an outstandingly tight fit.

Furutech’s already robust mounting flanges at top and bottom of each duplex outlet are held in place against the chassis with thick aluminium blocks applying pressure along the entire width of the flange rather than just securing it with screws at four points.

When Furutech says Pure Transmission, they mean it. Each duplex receptacle is additionally stabilized with double Axial Locks; a pair of special factory-torqued screws anchor the back of each receptacle at two points for ultimate mechanical integrity.

Four elegantly machined adjustable footers keep the Pure Power 6 stable for your system’s power cords. Run digital into one duplex, analogue front-end components into another, and your amplifier on the third for stunning, unrestricted, clean, stable AC power and rich, dynamic sound.

The three duplex receptacles are not wired to the incoming ground; they “float” electrically. The green ground wire from the incoming IEC fitting is tightly fixed to the chassis at the bottom of the centre chamber before it’s filled with GC-303, which further isolates the noisy ground. To ensure your safety the Power 6 must be grounded at its Grounding/Earthing Post located near the input IEC.

Nano Crystal² Formula (NCF)

Incorporated into selected Furutech products, NCF features a special crystalline material that has two 'active' properties. First, it generates negative ions that eliminate static. Second, it converts thermal energy into far-infrared. Furutech combines this remarkable material with nano-sized ceramic particles and carbon powder for their additional 'piezoelectric effect' damping properties. The resulting Nano Crystal² Formula is the ultimate electrical and mechanical damping material. Created by Furutech, it is found exclusively in Furutech products.

Specifications:

• Chassis: CNC machined aerospace-grade aluminum alloy
• AC Input/Output: 15A IEC input/3 UL-Rated duplex receptacles OR 15A IEC input/ 6 Rhodium-plated Schuko outlets
• Materials Processing: Metal parts treated with α (Alpha) Cryogenic and Demagnetizing Process
• Ground/Earth connection: Chassis Grounding Post
• IEC Inlet FI-09 NCF (R)- αpure copper conductor rhodium-plated
• Receptacles: 6 High End Performance GTX-D NCF (R) Duplex Receptacles OR 6 High End Performance FI-E30 NCF (R) Schuko sockets
• Internal wiring: 3 gauges of high quality twisted-multigauge Fluorpolymer-shielded high-purity silver-plated Alpha-OFC
• Solder: Special alloy solder
• Size: 8”/250mm W x 8”/250mm H x 3”/95mm D
• Weight: 22lbs/10kgs

About Furutech

Furutech, founded in 1988, designs and manufactures an extraordinary range of A/V cables made with extremely high purity OCC single-crystal oxygen-free copper. Furutech has several complete lines of analogue and digital, power and coaxial cables available in terminated and bulk quantities. Furutech makes a wide range of highest quality OEM A/V connectors and other signal transfer parts including power, speaker, IEC and specialized Hyper Audio Quality outlet receptacles. All metal components are treated with Furutech’s proprietary 2-Stage Alpha Cryogenic and Ring Demagnetization Process during manufacture that ensures the lowest achievable levels of distortion and noise.

Furutech offers a full line of elegantly engineered and designed power distribution and filter components made with an attention to detail found nowhere elsewhere. Furutech knows each and every part of the chain, no matter how small, is as important as the next, so they lavish maximum attention on all aspects of AC power transfer. As with cables, the separate parts go through the complete Alpha Process and also benefit from the effects of GC-303, an applied material that absorbs EMI (Electromagnetic Interference). Furutech's Reference Line of cables and interconnects also include this anti-EMI technology.

Furutech's multistep and highly specialized techniques result in an extremely low-noise, fast and undistorted signal transfer that begins with the incoming AC mains power, an important factor overlooked by many.

At Furutech, everyone is passionately devoted to reaching the highest watermark in reference-grade A/V cables, OEM parts and accessories for home and car audio where Furutech maintain a very strong presence. Furutech's mission is building the absolutely best products imaginable whatever the effort involved, and offering them at a price/performance ratio that deeply satisfies every purchaser. Furutech’s Pure Transmission Design Concept improves every element of signal transmission, from the AC to the speaker.
