The Best of Two Worlds Power & Precision ECO MKII linear audio upgrade power supply (BOTW P&P ECO) is the successor of Sbooster's BOTW P&P ECO, which was introduced in the summer of 2015. The BOTW P&P ECO upgrade power supply combines power, precision and efficiency in a unique innovative manner and is the best choice for every audiophile.

With the BOTW P&P ECO audio upgrade, the purification of the current starts immediately there where the polluted current enters the upgrade. The dual-stage mains filter and an earth line choke clean the current from high-frequency pollution before the current reaches the transformer. The transformer is a custom-made audio grade transformer with electrostatic shielding and is magnetically shielded.

The electronic design is innovative: it gets 50% more output out of the used electronics and consumes even up to 35% less energy than a conventional design. The BOTW P&P ECO audio upgrade concept is so efficient that it consumes only a bit more energy than the standard supplied high efficient, but also highly polluting switch mode adapter. It costs you annually a couple of euro extra on your energy bill for a priceless sound experience.

Finally, at the end of the DC cable, the unique split current system has been placed. The power supply of the BOTW P&P ECO audio upgrade provides the split current system with continuous powerful and clean power, so the electronics can do their job profoundly, which is to buffer the power, so that the power supply becomes very fast, and to filter one last time the voltage and current before they enter the audio device.

This unique upgrade power supply with its large headroom delivers at all times sufficient clean power to the audio device to ensure a stable and continuous performance of the internal processes of the audio device in order to get the best performance out of the audio device.

This combination of power and precision results in “easy” music, a perfect soundstage and a natural detailed sound.

This Sbooster Power Supply is a great upgrade for your Rega turntable. Most Rega turntables have a 24V power supply so upgrading to the BOTW MKII 24V will further enhance the sound from your turntable. See the list below of other compatible equipment and please contact Future Shop if your device is not listed.



Features:

• 50% more output current
• Power saving design
• 2 characteristics in 1 product - power for high current demanding equipment and precision for noise-sensitive equipment
• 3 selectable output voltages
• IEC 14 power inlet for High-end mains cables
• High-performance dual stage mains filter
• Earth line choke
• Overvoltage protection
• Custom made high efficient audio grade transformer
• High-quality polypropylene film capacitors
• No-noise Sbooster split current system
• High-quality PCB with double-sided 2oz. copper and a gold plated finish
• Better and thicker quality heatsink
• High-quality silver-plated copper with PTFE insulation internal wiring
• Transformer with electrostatic shielding and HF magnetic shielding
• Upgraded bulk capacitors
• Improved reference-circuit
• Next-generation split-current unit
• New DC-output cable with additional shielding, sleeve and gold plated connector pins
• Custom-made DC-plugs



Sbooster 24V for Rega Turntables

The Sbooster 24V Linear Power Supply is the perfect next-step upgrade for your Rega turntable and can bring your listening experience to new heights.

Tried and tested by Rega enthusiasts, the 24V Sbooster can offer enhanced vocal clarity, a more natural present soundstage and richer instrumentation. These are just some of the improvements heard by long-time Rega listeners.

Even more so, this opens up an entirely new upgrade path with improved power cables and fuses for the cable and Sbooster.

Here are some thoughts from the community!

"There was more fullness in the trumpet, the whole soundscape became a little more delicious and smooth in the cool way, and it was as if the musicians took a step further into the room and became more present. The strokes on the piano got a little more life and the overall impression became cleaner. As if the background was cleaned up a little."

"Without the Sbooster, it was as if there was a bit of harshness in the sound in some places in this track, and it disappeared with the Sbooster in place. The big drum got more depth and the music just became more relevant and maybe also more natural."

"If you like a thinner sound with special focus on the very high tones, and if you prefer this to fullness and presence in the sound, then you have to do this test yourself and find your own conclusion. Personally, I have no doubt: Sbooster is a definite plus for my taste!"





Compatibility List

If your equipment is not listed below, please do not hesitate to contact Future Shop and we will confirm compatibility between the Sbooster BOTW MKII Linear Power Supply and your device.

Brand	Model	Device type
Creek	OBH-11	Headphone Amp
Creek	OBH-15 Mk2	Phono Preamplifier
Creek	OBH-21MK2	Headphone Amp
Dr. Feikert	Woodpecker *	Turntable
Graham Slee	Accession	Phono Preamplifier
Graham Slee	Elevator EXP	Preamplifier
Graham Slee	Era Gold V	Phono Preamplifier
Graham Slee	Gram Amp 2	Phono Preamplifier
Graham Slee	Gram Amp 3	Phono Preamplifier
Graham Slee	Jazz	Phono Preamplifier
Graham Slee	Novo	Headphone Amp
Graham Slee	Reflex C	Phono Preamplifier
Graham Slee	Reflex M	Phono Preamplifier
Graham Slee	Revelation	Phono Preamplifier
Graham Slee	Solo	Headphone Amp
Musical Surroundings	Phonomena II+	Phono Preamplifier
Octave	EQ.2 **	Phono Preamplifier
Pathos Acoustics SRL	Converto	DAC
Rothwell	Rialto	Phono stage
Rothwell	Simplex	Phono stage
Rothwell	Headspace	Headphone Amp
Rupert Neve	RNHP	Headphone Amp
Soundsmith	MMP3 / MMP4 / MCP2	Phono Preamplifier
Soundsmith	SG200 - SG210 - SG230	Phono Preamplifier
Rega	P8	Turntable

* - Requires a special DC extension adapter cable which is available upon request.

** - Requires a 3.5mm Jack which is available upon request.



"We started with the excellent German Tumeter Till Bronner, and already here from the very first track we experienced a very clear and distinct, positive trend when we listened via Sbooster." "Without the Sbooster, it was as if there was a bit of harshness in the sound in some places in this track, and it disappeared with the Sbooster in place." Mikael Arendt Laursen



Specification

• Output Voltage & Current: 24V - 1.1A
• Mains Voltage: 230V 50/60Hz as standard (Alternatives available upon request)
• Transformer: 50VA audio grade toroidal with electrostatic and magnetic shielding
• Mains filter: High-performance dual stage mains filter with earth line choke
• Rectifier bridge: Power Schottky barrier rectifiers
• Bulk capacitors: 5 x Nichicon 4700µF + 1 x 5600µF + 1 Rubycon 330µF Low Impedance High Ripple Current Capacitors
• Regulator: High-current ultra-fast transient response LDO with an external high precision shunt reference circuit
• Filter capacitors: Non-inductive polypropylene film capacitors
• DC power cord: 95cm 16 AWG spiral shielded, additional shielding and quality sleeving, integrated Sbooster Split-current system and interchangeable gold plated DC-plug-connector
• UK mains cable supplied
• Size and Weight: 240*130*75mm 1.85Kg
• Safety approvals: CE/GS/CCC/KC/CTUVUS/FCC/PSB IEC60065 standard
• Warranty: 24 Months

Package Includes

• 1x BOTW P&P ECO Linear Power Supply
• 1x DC tip 0.7 x 2.5 x 9.5mm
• 1x DC tip 1.3 x 3.5 x 9.5mm
• 1x DC tip 1.7 x 4.0 x 9.5mm
• 1x DC tip 1.7 x 4.8 x 9.5mm
• 1x DC tip 2.1 x 5.5 x 9.5mm
• 1x DC tip 2.5 x 5.5 x 9.5mm
• 1x Manual
• 1x UK Mains cable
